Help CenterFuel Saving Series Diesel Engine/Fuel Saving Diesel Engine
Related Products
-
ZH1115 Jiangdong Single Cylinder Diesel EngineUS$ 1 - 699MOQ: 1 Set -
JD170 Single Cylinder Diesel EngineUS$ 170 - 770MOQ: 1 Set
-
ZS1110 Single Cylinder Diesel EngineUS$ 111 - 777MOQ: 1 Set
-
S195 Single Cylinder Water-cooled Diesel EngineUS$ 111 - 777MOQ: 1 Set
-
Brushless Single-phase 3hp Gasoline Engine Price, Small Gasoline EngineUS$ 599 - 599MOQ: 1 Set
JD Group- diesel engine and gasoline/petrol engine with series as below:
- 1. Single-cylinder diesel engine
1) Small horsepower series:
Exquisite appearance to meet demand of high-end customer
Energy-saving injector featuring low fuel consumption and long service life
China II emission certification
2000h reliability test
2) Large horsepower series:
Large torque: ensure demand for power during starting and climbing with heavy load and acceleration for overtaking
Low emission: ensure smoke intensity≤4.0 at full load while ensuring large torque at low speed
Low fuel consumption: fuel consumption≤215g/kw.h at maximum torque, and fuel consumption rate 224g/kw.h at normal rotating speed to minimize the operating cost of the diesel engine
Finite element analysis of engine block and cylinder head, and high strength and stiffness characteristic meeting rigorous service conditions
Proprietary gear train, super-long stroke design and strong power
Air intake and exhaust passage developed by CAE technology to achieve perfect matching with the fuel injection system
Anti-reverse-rotation ignition molded line design of camshaft
Cast (forged) steel balance shaft
- 2. Multi-cylinder diesel engine
International standard flywheel house connector, various connector supporting
Supporting domestic high-level fuel system, with sufficient combustion and low fuel consumption
Large heat dissipation area water tank, improving reliability and durability
Supporting 24V inside-regulator engine and fully-guarded starter, with compact structure, stable performance and long life
Hand lever oil switch on the oil pan, convenient for maintenance
2-level air cleaner with high filtration efficiency, improving engine reliability
- 3. Air-cooled diesel engine
Low fuel consumption
Light weight and compact design
Simple and rapid starting
Available in rigorous condition
Recoil starting or electric starting
Advanced fuel injection technology
Advanced noise reduction design
- 4. Gasoline engine
Long service life of engine, maintenance frequency reduced and noise reduction
Reasonable gasoline engine to ensure more complete combustion and stronger power output
Reasonable air-fuel ratio of carburetor
CAE-analyzed high strength engine components to ensure 800h failure-free operation
Advantage:
1.Low price
2.Fuel saving
3.Econmic and durale
4.Can be used in agriculture
Specifictions:
Model | ZH1110 | ZH1110N | ZH1110D | ZH1110ND | ZH1110WP | |
Type | Single-cylinder,Horizontal,4-cycle | |||||
Combustion | Direct Injection | |||||
Bore×Stroke(mm) | 110×115 | 110×115 | 110×115 | 110×115 | 110×115 | |
Displacement(L) | 1.093 | 1.093 | 1.093 | 1.093 | 1.093 | |
Compression Ratio | 17:1 | |||||
Output/Speed(HP/rpm) | 18/2200 | 18/2200 | 18/2200 | 18/2200 | 18/2200 | |
Cooling System | Evaporative | Radiator | Evaporative | Radiator | Evaporative | |
Lubrication System | Combined Pressure and Splash | |||||
Starting Method(kg) | Hand Cranking | Hand Cranking | Starting Motor | Starting Motor | Hand Cranking | |
Net Weight(kg) | 180 | 180 | 185 | 185 | 185 | |
Packing Size(mm) | L | 900 | 900 | 900 | 900 | 900 |
W | 440 | 440 | 440 | 440 | 440 | |
H | 760 | 760 | 760 | 760 | 760 | |
20FT unit | 96 | 96 | 96 | 96 | 96 | |
For related accesories, welcome to inform us.
