Help CenterSL420 OHV 4-stroke Single Cylinder Gasoline Engine/air Cooled Gasoline Engine
Related Products
-
SL340 OHV 4-stroke Gasoline EngineUS$ 100 - 450MOQ: 1 Set -
SL270 4-stroke Gasoline EngineUS$ 100 - 450MOQ: 1 Set
-
SL240 Small Gasoline EngineUS$ 100 - 450MOQ: 1 Set
-
SL200 Small Gasoline EngineUS$ 100 - 450MOQ: 5 Sets
-
5.5hp/3600rpm Potable Vertical Slow Speed Gasoline EngineUS$ 100 - 450MOQ: 5 Sets
JD Group- diesel engine and gasoline/petrol engine with series as below:
- 1. Single-cylinder diesel engine
1) Small horsepower series:
Exquisite appearance to meet demand of high-end customer
Energy-saving injector featuring low fuel consumption and long service life
China II emission certification
2000h reliability test
2) Large horsepower series:
Large torque: ensure demand for power during starting and climbing with heavy load and acceleration for overtaking
Low emission: ensure smoke intensity≤4.0 at full load while ensuring large torque at low speed
Low fuel consumption: fuel consumption≤215g/kw.h at maximum torque, and fuel consumption rate 224g/kw.h at normal rotating speed to minimize the operating cost of the diesel engine
Finite element analysis of engine block and cylinder head, and high strength and stiffness characteristic meeting rigorous service conditions
Proprietary gear train, super-long stroke design and strong power
Air intake and exhaust passage developed by CAE technology to achieve perfect matching with the fuel injection system
Anti-reverse-rotation ignition molded line design of camshaft
Cast (forged) steel balance shaft
- 2. Multi-cylinder diesel engine
International standard flywheel house connector, various connector supporting
Supporting domestic high-level fuel system, with sufficient combustion and low fuel consumption
Large heat dissipation area water tank, improving reliability and durability
Supporting 24V inside-regulator engine and fully-guarded starter, with compact structure, stable performance and long life
Hand lever oil switch on the oil pan, convenient for maintenance
2-level air cleaner with high filtration efficiency, improving engine reliability
- 3. Air-cooled diesel engine
Low fuel consumption
Light weight and compact design
Simple and rapid starting
Available in rigorous condition
Recoil starting or electric starting
Advanced fuel injection technology
Advanced noise reduction design
- 4. Gasoline engine
Long service life of engine, maintenance frequency reduced and noise reduction
Reasonable gasoline engine to ensure more complete combustion and stronger power output
Reasonable air-fuel ratio of carburetor
CAE-analyzed high strength engine components to ensure 800h failure-free operation
SL420 4-stroke gasoline engine
Specification:
Model | SL420 |
| Engine Type | OHV 4-STroke, 25° inclined, single cylinder with Air-cooled |
| Bore*Stroke (mm) | 90*66 |
| Displacement (ml) | 420 |
| Compression Ratio | 8.0:1 |
| Max. Output (HP/rpm) | 15.0/3600 |
| Max. Torque(N*m/rpm) | 28/2500 |
| Ignition system | Non-cntact transistorized ignition |
| Start mode | Recoil and hand-operated/Electric start |
| Air cleaner | Semi-dr, oil bath, dual, double silent and cyclone type |
| Fuel tank capacity(L) | 6.5 |
| Fuel consumption (g/hp-hour) | 260 |
| Engine oil capacity (L) | 1.1 |
| Dimensions (mm) | 555*435*510 |
| Net weight (kg) | 38 |
| 20/40FT unit | 354/786 |
About our factory:
YANCHENG SLONG MACHINERY & ELECTRIC CO.,LTD is located in DAFENG INDUSTRIAL PARK, CHANGZHOU NATIONAL HI-TECH DISTRICT, mainly deal with the Research & Development, Manufacture and Sales of various gasoline, diesel utility engine
and the machinery depending on gasoline, diesel engine as core power. The annual production output has reached 300,000 sets,
the products including: gasoline utility engine, diesel engine, generators series, water pump series, air compressor series, gardening machinery, construction machinery and agricultural machinery etc.
