Help CenterSL3800 Gasoline Generator
Related Products
Specifications
SL3800 Gasoline GeneratorStable output
Attractive shape with shining color
Long life and easy for maintenance
| Model | SL3800 | |
| Generator | Type | Brush, Brushless ,Single-phase |
| Voltage Regulate | AVR | |
| Frequency (Hz) | 50/60 | |
| Max. AC Output (KVA) | 3.0/3.5 | |
| Rated AC Voltage (V) | 110/120/220/230/240 | |
| Rated AC Outout (KVA) | 3.3/3.8 | |
| Power Factor | COSΦ=1 | |
| Model | SL240 | |
| Engine | Type |
OHV Forced Air-cooled 4-stroke |
| bore*stroke(mm) | 73*58 | |
| Dispalcement (ml) | 242 | |
| Compression Ratio | 8.5:1 | |
| Max. output (HP/rpm) | 8.0/3600 | |
| Fuel | Unleaded Gasoline | |
| Fuel tank capacity(L) | 25 | |
| Continuous operating hours (h) | 12.5 | |
| Oil | SF or Higher Grade | |
| Oil capacity(L) | 1.1 | |
| Ignition system | T.C.I | |
| Start system | Recoil and hand-operated/Electric start | |
| Operating noise level (dB) | 70 | |
| Standard features | Fuel gauge | 0 |
| Voltmeter | 0 | |
| AC circuit breaker | 0 | |
| Engine switch | 0 | |
| DC socket | 0 | |
| Optional features | DC output | + |
| DC circuit breaker | + | |
| Pilot light | + | |
| Package dimension | Dimensions L*W*H(mm) | 700*525*580 |
| Gross weight (kg) | 69 | |
| Net weight (kg) | 65 | |
Features
•A compact and light portable power for recreation emergency use.
•Start easily with a light pull.
•Overload protector for safe running.
•Easy maintenance with alternator electronic ignition.
About our factory:
Ourfactory mainly deal with the Research & Development, Manufacture and Sales of various gasoline, diesel utility engine and the machinery depending on gasoline, diesel engine as core power. The annual production output has reached 300,000 sets, the products including: gasoline utility engine, diesel engine, generators series, water pump series, air compressor series, gardening machinery, construction machinery and agricultural machinery etc.
With the Strong ability of Research & Development, Advanced Quality Management System and professional Quality Inspection Centre, our products quality has reached the first class level of the same sort products at home.
With the complete marketing network, our products have been sold to the customers in most part of China, and also have been exported to more than 80 countries and areas such as Southeast Asia, Africa, Middle-East, South America, Europe, USA etc.
