WYL4.0-E Excavator

Specifications

1. All the sheet metal structure parts use gas welding. The chassis uses reinforced disc structure. The weight of the body is scientific and reasonable.
2. Drive uses special engineering double-wheel drive, which strengthens the performance of the whole machine.
3. Work front leg uses oblique support type, which strenghens the operation stability of grab.
4. The direction uses hydraulic boost direction. Excavation operation is integrated with stepping operation, which makes operation more convenient.
5. Cab, engine shield, etc. use flow-line design, with reasonable structure, pretty and decent apperance and good closure performance.
6. Engine shield uses hinge type structure, which makes repair and maintenance more convenient.
7. Widely applying to the industries such as brickyard, sandpit, stone material factory, coal mine and water conservancy construction and building engineering, etc.

(WYL4.0-E)Excavator performance parameter

Item                               Specification

Engine Model              WEICHAI ZH4100

Engine Type               line four stroke;Water coolingSpurts the type straight

Engine Rated Power                      45KW

Rated Output Crpm                       2500r/min

Maximum Torque                          186 N.M

Main Oil Pump Model                      CBG2063

Displacement                             63ml/r

Biggest Working Pressure                 16MPa

Operating Weightkg)                    4000

Budket Capacity                          0.3m³

Overal Dimensions(mm)                  6600*1860*2350

Min Base to the ground(mm)                220

Wheel Distance (mm)                       1320

Axle-base (mm)                            2500

Support Leg Distance(mm)                  2365

Biggest Excavation Radius(mm)             5200

Biggest Excavation Altitude(mm)           5600

Biggest Digging Depth(mm)                 2500

Biggest Unloading Altitude(mm)            3650

Scoop Widthmm(mm)                         660

Biggest Climbing Power                    25

Highest Moving Velocity(km/h)             32

Loader clearance radius(mm)              2700

Biggest excavation strength(KN)          18.3

Hydraulic Cycle Time(S)                  11-16
