zl08 mini wheel loaderwith CE BV certificate
800kg wheel loader
0.4m3 bucket
rear wheel drive
Features
1. The ZL08A wheel loader uses the branded DI diesel engine as power, so it has the advantages of easy start, less oil consumption, strong power and environmental protection.
2. Using the dedicated engineering axles, the machine can make improvement for integral mechanical gearboxes, dual steering cylinders and so on, and can facilitate the operation.
3. The wheel loader uses the branded big-flow hydraulic pumps and steering gear. The hoisting arms, direction change and so on take less time and the work efficiency is greatly increased through its matching with the diesel engine.
4. With 24V battery (dual battery), the wheel loader will have an easy start in winter.
5. Its branded and high-quality rubber tire is far better for long-time operations in various environments.
6. The wheel loader employs the high-articulated structure (the distance between upper and lower hinge plates is short and the turning radius is small) to further stabilize the driving operation.
7. Featuring unique appearance, the cab of the wheel loader has a large operating space and wide vision so the machine achieves much safer operation.
8. The wheel loader has anoverhauled cover that is easy for maintenance.
Technical Specifications
Main Technical Parameter of ZL08 | |
Item | Parameter |
Rated load (kg) | 800 |
Bucket capacity (m3) | 0.4 |
Wheel tread (mm) | 1160 |
Wheel base (mm) | 1620 |
Min turning radius (mm) | 3000 |
Min ground clearance (mm) | 220 |
Dumping height (mm) | 2300 |
Corresponding dumping reach (mm) | 900 |
Lifting time (s) | 4.5 |
Hydraulic cycle time (s) | 9 |
Maximum excavating force (KN) | 21 |
Drive mode | Rear Wheel Drive |
Machine weight (kg) | 2000 |
Overall dimensions (mm) (Length*width*height) | 4480*1400*2200 |
Engine model | ChangchaiL22 |
Rated power of engine (kw) | 15.5 |
Rated speed of engine (rpm) | 2200 |
We are the professional and big manufacturer of the loaders and forklifts for over 17 years .
Our main products are as follows:
800kg wheel loader ZL08A ZL08B
1000kg wheel loader ZL10A ZL10B ZL10F SWM610
1200kg wheel loader ZL12F (best sell model) SWM615 SWM618
1600kg wheel loader ZL16F
2000kg wheel loader SWM620
3500kg wheel loader SWM635
5000kg wheel loader SWM952
Rough Terrain Forklift --Hot Sale
2800kg CPCY28
3500kg CPCY35
5000kg CPCY50
10000kg CPCY100
Diesel Forklift
3000kg and 3500kg CPC30 CPC35
Electric Forklift
1500kg CPD15
It is our great pleasure to receive your specific inquiries .
Please send us inquiries or send email to directly .
Our best wishes to you and your esteemed company . :) O(∩_∩)O
