Loader Mini

mini loader 4wd

Features
1. The ZL08-I wheel loader uses the branded DI diesel engine as power, so it has the advantages of easy start, less oil consumption, strong power and environmental protection.
2. Using the dedicated engineering axles, the machine can make improvement for integral mechanical gearboxes, dual steering cylinders and so on, and can facilitate the operation.
3. The wheel loader uses the branded big-flow hydraulic pumps and steering gear. The hoisting arms, direction change and so on take less time and the work efficiency is greatly increased through its matching with the diesel engine.
4. With 24V battery (dual battery), the wheel loader will have an easy start in winter.
5. Its branded and high-quality rubber tire is far better for long-time operations in various environments.
6. The wheel loader employs the high-articulated structure (the distance between upper and lower hinge plates is short and the turning radius is small) to further stabilize the driving operation.
7. Featuring unique appearance, the cab of the wheel loader has a large operating space and wide vision so the machine achieves much safer operation.
8. The wheel loader has anoverhauled cover that is easy for maintenance.

Main Technical Parameter of ZL08
Item	Parameter
Rated load (kg)	800
Bucket capacity (m3)	0.4
Wheel tread (mm)	1160
Wheel base (mm)	1620
Min turning radius (mm)	3000
Min ground clearance (mm)	220
Dumping height (mm)	2300
Corresponding dumping reach (mm)	900
Lifting time (s)	4.5
Hydraulic cycle time (s)	9
Maximum excavating force (KN)	21
Drive mode	Rear Wheel Drive
Machine weight (kg)	2000
Overall dimensions (mm) (Length*width*height)	4480*1400*2200
Engine model	ChangchaiL22
Rated power of engine (kw)	15.5
Rated speed of engine (rpm)	2200
