Mini Wheel Loader ZL08F

Specifications

Technical Specifications of Model ZL08F of Wheel Loaders    ( 4WD,  One-Cylinder)

1.0 Engine Details

(1) Model: Changcai L24
(2) Engine type: In-line arrangement, water cooled, one-cycle diesel Engine
(3) Rated Power: 17KW (24 H. P. )
(4) Rated Speed: 2200 r/min(rpm)
(5) Fuel Consumption ratio in standard working condition: 269g/kw. H

2.0 Steering System

(1) Cycloid full hydraulic steering system: BZZ-80
(2) System Pressure: 10MPa
(3) Steering Cylinder: Φ76x Φ63x160
(4) Speed
--i Forward shift (forward I) 7.19
--ii Forward shift (forward II) 3.35
--iii Reverse shift (Reverse I) 7.19
--iiii Reverse shift (Reverse II) 3.35

3.0 Bucket

(1) Bucket Capacity: 0.4 m3
(2) Bucket width: 1300mm
(3) Bucket type: Heavy duty bolt on teeth
(4) Max. Breakout Force: 22.5KN
(5) Rated Load: 800kg
(6) Operating Weight: 2000kg

4.0 Overall Dimension

(1) Overall Length ( Bucket on ground position ): 4480mm
(2) Overall Height
(a) Ground to Cab Top: 1400mm
(b) Ground to exhaust pipe: It is below from the top of cabin
(c) Dumping Height: 2300mm
(3) Overall Width: 2200mm

5.0 Operating Specifications

(1) Drive Means: Two-wheel drive
(2) Min Turning Radius: 3000mm
(3) Driving System: Mechanical
(4) Dumping Reach at max height: 900mm
(5) Min Base to the ground: 220mm
(6) Time of raise: 4.5sec.
(7) Hydraulic cycle time: 8.5sec.

6.0 Brake System

(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated

7.0 Wheelbase:

1620mm

8.0 Track:

1160mm
