SWM952, 5000kg wheel loader

Specifications

5000kg wheel loader
1. Rated load:5000Kg
2. Bucket capcity:2.5m3
3.Certificate:CE
4.Power:162Kw

Wheel  loader, 5000KG whee loader

1. Main data



Item	SWM952
Rated load (kg)	5000
Bucked  capacity(m3)	2.5
Wheel tread(mm)	2200
Wheel base(mm)	3310
Mini turning radius(mm)	7150
Mini ground clearance (mm)	395
Dumping height (mm)	3580
Corresponding dumping reach (mm)	1290
Lifting time(s)	5.9
Hydraulic cycle time(s)	11.4
Maximum excavating(KN)	186
Drive mode	Four-wheel drive
Machine weight(kg)	17150
Overall dimensions(mm)(length*width*height)	8365*3220*3390
Engine model	Weichai steyr WD615G-220
Rated power of engine(KW)	162
Rated speed of engine(RPM)	2200





Features

1. Heavy Duty Design

(1). The wheel loader uses a high-rigidity frame which is made of thickened steel and characterized by a large frame structure. The machine has the advantages of load-proof,automatic robot welding andanti-torsion.

(2). Equipped with a large-wheelbase underpan, the wheel loader can enhance the driving and operational stability, increase the traction and so on.

(3). With a heavy-duty transmission system featuring high overload resistance coefficient, fatigue resistance and long service life, the wheel loader is especially suitable for continuous high-intensity operation.

(4). Its large-diameter front and rear transmission shaft has the advantages of powerful anti-torsion capability, difficult deformation under heavy load, and stable transmission of kinetic energy.
