SWM952 wheel loader ,5000kg wheel loader with ce for sale

Specifications

wheel loader with ce
1. Rated load:5000Kg
2. Bucket capcity:2.5m3
3.Certificate:CE
4.Power:162Kw ,A/C



SHANDONG WEILI WORLD MACHINERY CO.,LTD





Features



1. Heavy Duty Design



(1). The wheel loader uses a high-rigidity frame which is made of thickened steel and characterized by a large frame structure. The machine has the advantages of load-proof,automatic robot welding andanti-torsion.

(2). Equipped with a large-wheelbase underpan, the wheel loader can enhance the driving and operational stability, increase the traction and so on.

(3). With a heavy-duty transmission system featuring high overload resistance coefficient, fatigue resistance and long service life, the wheel loader is especially suitable for continuous high-intensity operation.

(4). Its large-diameter front and rear transmission shaft has the advantages of powerful anti-torsion capability, difficult deformation under heavy load, and stable transmission of kinetic energy.





Technical Specifications







Main Technical Parameter of SWM952
Item	Parameter
Rated load (kg)	5000
Bucket capacity (m3)	2.5
Wheel tread (mm)	2200
Wheel base (mm)	3310
Min turning radius (mm)	7150
Min ground clearance (mm)	395
Dumping height (mm)	3580
Corresponding dumping reach (mm)	1292
Lifting time (s)	5.9
Hydraulic cycle time (s)	11.4
Maximum excavating force (KN)	186
Drive mode	Four are Drive
Machine weight (kg)	17150
Overall dimensions (mm) (Length*width*height)	8365*3220*3390
Engine model	TWD615G-220
Rated power of engine (kw)	162
Rated speed of engine (rpm)	2200
