SWLTD Wheel Loader ,SWM952 Wheel Loader

SWLTD Wheel Loader ,SWM952 Wheel Loader photo-1
Negotiable MOQ: 1 Roll (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
SWLTD
Model Number:
SWM952
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name SWLTD
Model Number SWM952
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 8365*3220*3390mm
Rated Load 5000kg
Certification CE BV ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

chinese wheel loader ,SWM952 wheel loader
1. Rated load:5000Kg
2. Bucket capcity:2.5m3
3.CE ISO BV
4.Power:162Kw ,A/C







Heavy Duty Design


(1). The wheel loader uses a high-rigidity frame which is made of thickened steel and characterized by a large frame structure. The machine has the advantages of load-proof,automatic robot welding andanti-torsion.


(2). Equipped with a large-wheelbase underpan, the wheel loader can enhance the driving and operational stability, increase the traction and so on.


(3). With a heavy-duty transmission system featuring high overload resistance coefficient, fatigue resistance and long service life, the wheel loader is especially suitable for continuous high-intensity operation.


(4). Its large-diameter front and rear transmission shaft has the advantages of powerful anti-torsion capability, difficult deformation under heavy load, and stable transmission of kinetic energy.





Wheel  loader, heavy equipment SWM952 , small construction equipment





1. Main data



Item

SWM952

Rated load (kg)

5000

Bucked  capacity(m3)

2.5

Wheel tread(mm)

2200

Wheel base(mm)

3310

Mini turning radius(mm)

7150

Mini ground clearance (mm)

395

Dumping height (mm)

3580

Corresponding dumping reach (mm)

1290

Lifting time(s)

5.9

Hydraulic cycle time(s)

11.4

Maximum excavating(KN)

186

Drive mode



Four-wheel drive

Machine weight(kg)

17150

Overall dimensions(mm)(length*width*height)

8365*3220*3390

Engine model

Weichai steyr WD615G-220

Rated power of engine(KW)

162

Rated speed of engine(RPM)

2200

SWLTD wheel loader ,SWM952 wheel loader

SWLTD wheel loader ,SWM952 wheel loader

SWLTD wheel loader ,SWM952 wheel loader

SWLTD wheel loader ,SWM952 wheel loader

SWLTD wheel loader ,SWM952 wheel loaderCE certificate

SWLTD wheel loader ,SWM952 wheel loaderISO9001:2008

SWLTD wheel loader ,SWM952 wheel loader





SWLTD wheel loader ,SWM952 wheel loader



SWLTD wheel loader ,SWM952 wheel loader



SWLTD wheel loader ,SWM952 wheel loader



SWLTD wheel loader ,SWM952 wheel loader
