Help CenterSWM952 Wheel Loader With ce for Sale
Related Products
Specifications
SWM952 wheel loader with ce for saleCE or EPA
Joystick valve
Engine:Weichai,ZF transmission
Hydraulic Pilot
Features
1. Heavy Duty Design
(1). The wheel loader uses a high-rigidity frame which is made of thickened steel and characterized by a large frame
structure. The machine has the advantages of load-proof,automatic robot welding andanti-torsion.
(2). Equipped with a large-wheelbase underpan, the wheel loader can enhance the driving and operational stability,
increase the traction and so on.
(3). With a heavy-duty transmission system featuring high overload resistance coefficient, fatigue resistance and long
service life, the wheel loader is especially suitable for continuous high-intensity operation.
(4). Its large-diameter front and rear transmission shaft has the advantages of powerful anti-torsion capability, difficult
deformation under heavy load, and stable transmission of kinetic energy.
2.Technical Specifications
Main Technical Parameter of SWM952 | |
| Item | Parameter |
| Rated load (kg) | 5000 |
| Bucket capacity (m3) | 2.5 |
| Wheel tread (mm) | 2200 |
| Wheel base (mm) | 3310 |
| Min turning radius (mm) | 7150 |
| Min ground clearance (mm) | 395 |
| Dumping height (mm) | 3580 |
| Corresponding dumping reach (mm) | 1292 |
| Lifting time (s) | 5.9 |
| Hydraulic cycle time (s) | 11.4 |
| Maximum excavating force (KN) | 186 |
| Drive mode | Four are Drive |
| Machine weight (kg) | 17150 |
| Overall dimensions (mm) (Length*width*height) | 8365*3220*3390 |
| Engine model | TWD615G-220 |
| Rated power of engine (kw) | 162 |
| Rated speed of engine (rpm) | 2200 |
Multi-function ,The SWM952 wheel loader can fit all kinds quick attach,working device as follows:
France BV Cetificate CE Certificate
We are the professional and big manufacturer of the loaders and forklifts for over 17 years .
Our main products are as follows:
800kg wheel loader ZL08A ZL08B
1000kg wheel loader ZL10A ZL10B ZL10F SWM610
1200kg wheel loader ZL12F (best sell model) SWM615 SWM618
1600kg wheel loader ZL16F
2000kg wheel loader SWM620
3500kg wheel loader SWM635
5000kg wheel loader SWM952
Rough Terrain Forklift --Hot Sale
2800kg CPCY28
3500kg CPCY35
5000kg CPCY50
10000kg CPCY100
Diesel Forklift
3000kg and 3500kg CPC30 CPC35
Electric Forklift
1500kg CPD15
It is our great pleasure to receive your specific inquiries .
Please send us inquiries or send email to directly .
Our best wishes to you and your esteemed company . :) O(∩_∩)O
