Help Center2014 New Design 11Hp Water Cooled Diesel Engine
Related Products
Specifications
1.Type: water-cooled2.Certificate: ISO9001:2008
3.Maximum output: 11(8.09) kw(Hp)
4.Rated speed: 2400 r/min
Fuel: diesel
Introduction to the Company
As a joint venture, Chongqing Golden Bow Group Power Co., Ltd. was founded by Chongqing Golden Bow
Group Co., Ltd. and a Thailand investor. With the registered capital of RMB 10 million and the fixed capital of
RMB 40 million, the company has powerful strength. In its standard industrial workshop of more than 10000m², the company has set up the modern production line, which has advanced equipments, complete and smooth techniques and stable performance. For its beautiful environment and complete environmental protection facilities such as waste disposal pool, air purifier and sound insulation belt, the company was named as Chongqing Green Environmental Protection Experimental Company.
Specialized in the engine production and having the rights of independent import and export, Golden Bow Group Power Co., Ltd. is a large manufacturing enterprise that owns high quality working staff and strong technology and exports all its products. With its leading products having many independent patents, the company has been engaged in the R&D of diesel engine for over 10 years and topped over the other rivals in product quality and exploit new products incessantly for satisfy the clients’ requirement.
Having set up the independent and complete sales network, the company has won the confidence from clients with excellent after-sales service and set up good market image.
The mission of Golden Bow Group Power Co., Ltd. is to be creative and innovative in technology, to be perfect in quality, to put the interests of clients the first place and offer them the sincere service. We hope that we can provide for our clients and friends better products and service.
Technical Specification
NO. |
ITEMS |
UNIT |
MODEL |
G120 | |||
1 |
Type |
|
Single cylinder, horizontal, water-cooled, 4-cycle |
2 |
Bore×stroke |
mm×mm |
94×90 |
3 |
Displacement |
mL |
625 |
4 |
Rated speed |
r/min |
2400 |
5 |
Continuous rated output |
Hp |
10.5 |
6 |
Max. output |
Hp |
12 |
7 |
Idle speed |
r/min |
≤600 |
8 |
Compression ratio |
|
21:1 |
9 |
Cooling system |
|
Radiator |
10 |
Combustion system |
|
(TVCS) Three vortex combustion system |
11 |
Fuel delivery position |
|
19°~21° |
12 |
Fuel injection pressure |
kgf/cm2 |
120~125 |
13 |
Lubricating system |
|
Forced lubrication with trochoid pump |
14 |
Starting system |
|
Electric startup,Speed doubling handle hand |
15 |
Direction of rotation |
|
Counter clockwise facing flywheel |
16 |
Cooling water capacity |
L |
2.1(Radiator) |
17 |
Fuel tank capacity |
L |
10 |
18 |
Crankcase oil capacity |
L |
2.3 |
19 |
Measurement |
mm |
765×350×520 |
20 |
Net weight |
kg |
117 |
