Sany 36tons All New Mobile Concrete Mixer Truck With Pump for Sale SYG5360THB 47

Sany 36tons All New Mobile Concrete Mixer Truck With Pump for Sale SYG5360THB 47 photo-1
US$ 60,000 - 75,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Diesel
Brand Name:
sany
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Power Type Diesel
Brand Name sany
Model Number SYG5360THB 47
Power(W) 30kw
Weight 36400 kg
Dimension(L*W*H) 12500 mm *2500 mm *4000 mm
Certification ISO
Warranty 12 Months
Product Description
Product Name
Sany 36tons all new mobile concrete mixer truck with pump for sale SYG5360THB 47
Length
12500 mm
Width
2500 mm
Height
4000 mm
Empty weight
36400 kg
Vertical reach
47 m
Horizontal reach
42 m
Reach depth
29.4 m
Unfolding reach
13.9 m
1st section-Length
9760 mm
1st section-Articulation
89°
2nd section-Length
7670 mm
2nd section-Articulation
180°
3rd section-Length
7410 mm
3rd section-Articulation
180°
4th section-Length
9670 mm
4th section-Articulation
235°
5th section-Length
8545 mm
5th section-Articulation
215°
Rotation
±360°
Outrigger spread L-R---front
9300 mm
Outrigger spread L-R---rear
9620 mm
Output (Low/High-pressure)
170/120 m?/h
Pressure (Low/High-pressure)
8.3/12 Mpa
Max. strokes per minute (Low/High-pressure)
29/19 times/min
Delivery cylinder diameter
260 mm
Stroke length
1900 mm
Hydraulic system
Open
Hydraulic system pressure
32 Mpa
Hydraulic tank capacity
680 L
Water tank capacity
620 L
Pipe size
125 mm
End hose length
3 m
End hose diameter
125 mm
Chassis model
BENZ Actros 4141
Engine type
OM501LA.Ⅳ/3
Engine power
300/1800 kW/rpm
Emission standard
Tier Ⅳ / Tier III (adjustable)
Capacity of fuel tank
400 L
Displacement
11.946 L
Max.speed
80 km/h
Brake distance
≤10/30 m/km/h
Benifits and feature

One Button Stabilization Technology

The one button stabilization technology quickly dampens any boom movement resulting from repositioning the boom. This allows precise positioning of the end hose. - See more at: /product/syg5271thb38.html#sthash.rR3tevgN.dpuf

Boom Anti Vibration Technology

The boom anti vibration technology reduces vibration during pumping by 50% allowing less movement and greater control of the end hose. - See more at: /product/syg5271thb38.html#sthash.rR3tevgN.dpuf

Energy Saving Technology

With cycle times of up to 29 per minute (at 12MPa), pump efficiency is increased up to 25% while fuel consumption is decreased by up to 10%. - See more at: /product/syg5271thb38.html#sthash.rR3tevgN.dpuf

Construction Cases


SANY SY5250THB-38 truck-mounted concrete pump undertook the pumping and placing task for the construction of the electric power plant in the state of Arkansas, USA. The user, Southland Machinery, was impressed with Sany product's high performance and superior after-sale service. He said:" SANY truck pump keeps stable operation that ensures the working progress. If there is any problem, SANY service engineer will solve it immediately.
