Specifications
JAC Car Carrier Truck1.diesel engine at 115ps.4X2,LHD
2.flatbed length5.55m, width2.3m
3.3C ISO BV appro
JAC Car Carrier Truck
1.diesel engine at 115ps.4X2,LHD
2.flatbed length5.55m, width2.3m
3.3C ISO BV appro
HuBei chengli special automobile Co.,Ltd is a heavy automobile manfacture , the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseas customers and has cooperated with nearly 100 foreign customers from Africa, South Africa, the Middle East and South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks’ entrance to the international market. The company mainly deals with various heavy automobiles, refitting vehicles and various engineering machines. The heavy automobiles include Shaanqi series, Sinotruck series and the refitting vehicles include cement mixers, bulk cement trucks, various tank trucks and vans, etc. Besides, the company is an authorized dealer of Sinotruck, Shaanqi, Special Truck Company, CNHTC, CIMC Container Manufacture Co., Ltd., Zhongtong and other heavy automobile manufacturers and refitting enterprises. The company has established many offices at broad, achieving the so-called “bringing in and going out”.
Pls find the data parameter as below
Product |
Guaranteed 100% JAC Car Carrier Truck |
|
Cab |
Single row, with power assisted steering; Air-condition optional |
|
Traction |
4 Tons |
|
Lifting |
1.8 Tons |
|
|
Chassis |
Brand |
JAC |
Chassis model |
HFC1061K93 |
|
Drive type |
4×2, LHD |
|
Tire |
7.50-16 |
|
Tire No. |
6+1(spare) |
|
Braking System |
Air braking |
|
Clutch |
Uniwafer, dry clutch, hydraulic remote control |
|
Transmission |
5 forward gear,1 reverse gear,manual mechanical type |
|
Engine |
Model |
CY4102-C3D |
Horse Power(hp) |
115 |
|
Displacement(cc)/Power(kw) |
3856/80 |
|
Emission |
Euro 3 |
|
|
Main Parameters |
Overall dimension (L*W*H/mm) |
7150*2320*2420 |
Wheelbase(mm) |
3815 |
|
Axles No. |
2 |
|
GVW(kg) |
6125 |
|
Curb Weight(kg) |
4800 |
|
Leaf spring No. |
9/12 |
|
Approaching/Departure Angle(°) |
22/13 |
|
Front/Rear trace(mm) |
1525/1665 |
|
Front/Rear suspension(mm) |
1085/2250 |
|
Max speed(km/h) |
95 |
|
Front/Rear Axle Load(kg) |
2350/3775 |
|
Vehicle Special Function:
Flat-bed dimensions (L*W /mm): 5550*2300
Flat-bed Max capacity (kg): 3000
Max under-hoisting capacity (kg): 1800
Max hoisting capacity when telescopic boom all out (kg): 1330
Winch numbers: 1 unit
Max towing capacity of winch(kg): 4000
Max towing speed (km/h): 40
Length of steel wire rope: (m): 20
Speed of steel wire rope (m/min): 8
Equipments with this vehicle:
Long alarm lamp, 1 unit
Wrecker binding, 4units
Chain belt ,1 unit
Training wheels, 2units
Lift 1pair; Lift base 1unit
