Dongfeng 185hps motor vehicle wreckers
Road Wrecker
Product |
Dongfeng 185hps motor vehicle wreckers |
|||
Vehicle model |
JDF5160TQZG |
|||
Chassis model |
EQ5160GKJ |
|||
|
Chassis parameters |
Overall dimensions |
mm |
7440×2498×2920 |
|
Gross weight |
kg |
15600 |
||
Curb weight |
10705 |
|||
Suspension F/R |
mm |
1250/1490 |
||
Wheel base |
4500 |
|||
Drive type |
4*2 |
|||
Number of axles |
2 |
|||
Axle-load |
Kg |
5890/9710 |
||
Number of Spring leafs |
9/10+8 |
|||
Tire specification |
9.00-20,9.00R20,10.00-20,10.00R20 |
|||
Number of Tires |
6 |
|||
Allowable passengers in cab |
3 |
|||
Engine |
Engine model |
ISDe185 30 |
||
Type of fuel |
Diesel |
|||
Displacement/power |
ml/hp |
6700/185 |
||
Max speed |
Km/h |
80 |
||
Emission standard(TAS) |
EURO 3 |
|||
Other main equipments and parameters |
Main equipments |
Equipped with hydraulic pressure system, neat-structured, flexible and reliable |
||
Equipped with high-latitude signal lamp which can guarantee night barrier-cleaning work | ||||
Equipped with traction supporting highly flexible crane operated by the hydraulic pressure system | ||||
Lifting system |
Rated lifting weight(kg) |
9000 |
||
Effective length (mm) |
1800 |
|||
Platform Dimension (L*W) (mm) |
5240×2100 |
|||
Platform Moving length(mm) |
2680 |
|||
Qty of winch (pc) |
2 |
|||
Length of steel wire (m) |
21 |
|||
Bracket arm |
Bracket arm Telescope length (mm) |
1180 |
||
Max towing speed (km/h) |
40 |
|||
Platform Min inclination angle(°) |
10 |
|||
Platform max loading capacity(mm) |
6000 |
|||
Rated towing mass (kg) |
6000 |
|||
Winch Speed (m/min) |
8 |
|||
Payment terms and delivery:
Delivery date: 7-10 days
Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy
Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
