SX 9 tons towing tractor wrecker truck for sale

Product

SX 9 tons towing tractor wrecker truck

Vehicle model

YH5380TQZ29DZ

Chassis model

SX1315NM456

Chassis

parameters

Overall dimensions

mm

10795×2500×3370

Gross weight

kg

38000

Curb weight

25370

Suspension F/R

mm

1525/1620

Wheel base

1800+4500+1350

Drive type

8*4

Number of axles

4

Axle-load

Kg

7000/7000/24000

Number of Spring leafs

Left 14 right 13/left 14 right 13/12

Tire specification

12.00-20,11.00-20,11.00R20,12.00R20

Number of Tires

12

Allowable passengers in cab

2

Engine

Engine model

WP10.310E32

Type of fuel

Diesel

Displacement/power

ml/hp

9726/310

Max speed

Km/h

92

Emission standard(TAS)

EURO 3

Other main equipments and parameters

Main equipments

Equipped with hydraulic pressure system, neat-structured, flexible and reliable

Equipped with high-latitude signal lamp which can  guarantee night barrier-cleaning work

Equipped with traction supporting highly flexible crane operated by the hydraulic pressure system

Lifting system

Rated lifting weight(kg)

9000

Effective length (mm)

1800

Platform Dimension (L*W) (mm)

5240×2100

Platform Moving length(mm)

2680

Qty of winch  (pc)

2

Length of steel wire (m)

21

Bracket arm

Bracket arm Telescope length (mm)

1180

Max towing speed (km/h)

40

Platform Min inclination angle(°)

10

Platform max loading capacity(mm)

4000

Rated towing mass  (kg)

4000

Winch Speed  (m/min)

8
