Specifications
wrecker truck,road wrecker truck,road maintenance truckwrecker truck is used for the cars which broken
3C,ISO,BV
OEM
wrecker truck parameter:
Item |
Unit |
Parameter |
|
Model |
|
CLW5050TQZ Road Wrecker |
|
Chassis |
|
EQ1051G51DJ3A |
|
Overall dimension |
mm |
5995×2000×2290 |
|
Fact lift weight |
kg |
8000-1000 |
|
GVW |
kg |
Appro×5150 |
|
Rated Loading Capacity |
Appro×490 |
||
Mass in working order |
Appro×4530 |
||
Arm extension stroke of lift |
mm |
Approx630 |
|
Max loading weight |
kg |
Approx1200 |
|
Max starting power |
KN |
Approx26.4 |
|
Case dimension |
mm |
NO |
|
Wheel base |
3300 mm |
Engine type |
4100QBZL |
F/R track base |
1506/1466mm |
Exhaust/hp |
3298/70 ml/kw |
F/R over hang |
962/1733mm |
fuel consumption / 100 km |
13L |
Approach/Departure angle |
23/20 ° |
Min turning radius |
12 m |
Max speed |
90 km/h |
Max grade ability |
25° |
Tire |
6.50-16,7.00-16 |
Min ground clearance |
180 mm |
Armor plate spring quantity |
6/8+4 |
Gearbox |
5 speeds |
Brake System |
Exhaust brake |
Clutch |
242 mm |
Brake space |
8m |
Air condition |
optional |
Front/Rear axles |
1.5/3.5 T |
Frame |
188 mm |
Traction system |
4×2 |
Electric system |
12v |
Number of axles |
2 |
Allowable passengers in cab |
2 |
