DongFeng Mini Truck Mounted Crane,small Truck Crane,truck With Crane

DongFeng Mini Truck Mounted Crane,small Truck Crane,truck With Crane photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Plant, port,street etc.
Rated Loading Capacity:
4800
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Plant, port,street etc.
Rated Loading Capacity 4800
Rated Lifting Moment 7.6
Max. Lifting Load 3200
Max. Lifting Height 7.3
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW5110JSQ3
Certification iso,ccc

Specifications

truck mounted crane
1.Max lifting capacity is 3200kg
2.China supplier price
3.XCMG&Chengli crane choose
c,bv,iso




Product Description







12 ton XCMG crane truck manufacturer in China



 Crane Truck Parameters



We are a professional manufacturer, we have our own workshop and technical personnel,We can produce all kinds of size of the  truck mount crane .





MAIN TECHNICAL PARAMETERS
product name truck mounted cranes XCMG (truck with loading crane) overall dimensions(mm) 7050×2420×3150,3230
gross vehicle weight(kg) 11495 cargo box body dimensions(mm) 4300,4200×2050×550
rated loading weight(kg) 5,970,600,058,605,830 rated passenger number in cab 3
unladen weight(kg) 5,330,530,054,405,470 approach/departure angle(°) 360
suspension front/rear(mm) 1180/2070 axle number 2
distance between shafts(mm) 3800 axle loading weight(kg) 4050/7445,4040/7455,
4100/7395,4115/7380
top speed(km/h) 90
NOTE 1.crane type: folding arm, crane model/quality (kg)/maximum lifting crane load (kg)/vehicle unladen weight (kg)/ corresponding to the rated load quality(kg):
SQ3.2S:1150Kg/3200Kg/5330Kg/5970Kg;
SQ3.2Z:1080Kg/3200Kg/5300Kg/6000Kg;
SQ4S:1220Kg/4000Kg/5440Kg/5860Kg;
SQ4Z:1250Kg/4000Kg/5470Kg/5830Kg .
2.When the weight change as a result of choosing different cargo box dimensions is less than 3%,then this value of number could be ignored.
3. According to the chassis, we choose cab. Fence material: Q235 carbon, Left and right side and bottom protection are connected by welding. The back of the protective section size(mm):100*50*5. the rear part height from the ground is 520 mm .







 Images







DongFeng mini truck mounted crane,small truck crane,truck with craneDongFeng mini truck mounted crane,small truck crane,truck with craneDongFeng mini truck mounted crane,small truck crane,truck with crane








Packaging & Shipping







Crane truck, hydraulic crane car,mobile crane lorry Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements.Ensure that the new car arrive 100% safe.








Our Services





After-sale Service One year warranty Any small question will be solved at the most prompt time. We also offer relative technical support. Our spare parts will be available at any time after your order.

Supply Capacity

We manufacture the truck as soon as your order comes. And for the stock, we can delivery it immediately.

For more details, please just feel free to contact me.






Company Information







ChengLi special automobile co.,LTD Factory Supply:

a.special truck manufacturers in Suizhou city,HuBei province, china,

b.more than 100 kinds of special truck for your needing.such as garbage truck,LPG truck ,fuel truck  , water truck ,high platform truck , dump truck , concrete mixer truck ,truck mounted crane ,chemical tank truck , fire fighting truck ,bulk cement truck ,flat bed trailers , low bed trailer , cargo trailer tipper trailer ,fuel trailer ,LPG trailer and more

c.Nearly 15 years Wholesaler experience inproduce truck and truck parts field






FAQ









1.How about quality of your factory quality ?



A:All our trucks 100% new .All our trucks got ISO 9001:2008 and CCC and B&V certificate ,and many truck passed SGS inspection .All our chassis and spare parts are from the original manufacturers with original part number and and anti-fake label, all our suppliers have passed the SGS,BV, and CONTECNA qualification certification, the quality is 100% guaranteed.



2. How many years of your company's service, especially after-sale service?



A: Chengli special automobile Co.,Ltd has been in this field for nearly 15 years and has strong production and distribution capability,we can produce your products in 15 working days.We offer after-sale service 1 year.
