Specifications
Famous brand dongfeng 4-5T /truck mounted hydraulic cranes truck with crane1.Cummins170hp engine, Euro 3
2.crane optional 4T
Famous brand dongfeng 4-5T /truck mounted hydraulic cranes truck with crane
1.Cummins170hp engine, Euro 3
2.crane optional 4T/5T
3.cargo length:4.5m
HuBei chengli special automobile Co.,Ltd is a heavy automobile manfacture , the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseas customers and has cooperated with nearly 100 foreign customers from Africa, South Africa, the Middle East and South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks’ entrance to the international market. The company mainly deals with various heavy automobiles, refitting vehicles and various engineering machines. The heavy automobiles include Shaanqi series, Sinotruck series and the refitting vehicles include cement mixers, bulk cement trucks, various tank trucks and vans, etc. Besides, the company is an authorized dealer of Sinotruck, Shaanqi, Special Truck Company, CNHTC, CIMC Container Manufacture Co., Ltd., Zhongtong and other heavy automobile manufacturers and refitting enterprises. The company has established many offices at broad, achieving the so-called “bringing in and going out”.
Pls find the data parameter as below
Product | DONGFENG145 Truck mounted 5Ton loader cranes | |
Chassis | Brand | DONGFENG |
Chassis model | EQ1110GLJ3 | |
Drive type | 4×2, LHD/RHD | |
Tire | 9.00-20 | |
Tire No. | 6+1(spare) | |
Braking System | Air braking, cam drum braking | |
Clutch | Uniwafer, dry clutch, hydraulic remote control | |
Transmission | 5 forward gear,1 reverse gear,manual mechanical type | |
Engine | Model | B170-33 |
Horse Power(hp) | 170 | |
Displacement(cc)/Power(kw) | 5900/125 | |
Emission | Euro 3 | |
Main Parameters | Overall dimension (L*W*H/mm) | 8000*2470*3500 |
Cargo dimension (L*W*H/mm) | 4500*2294*1000 | |
Wheelbase(mm) | 4700 | |
Axles No. | 2 | |
GVW(kg) | 11495 | |
Curb Weight(kg) | 7700 | |
Leaf spring No. | 8/11+8 | |
Approaching/Departure Angle(°) | 33/14 | |
Front/Rear trace(mm) | 1900/1800 | |
Front/Rear suspension(mm) | 1250/2050 | |
Max speed(km/h) | 90 | |
Front/Rear Axle Load(kg) | 4500/6995 | |
Cab | Non-long headed cabin; Air-condition optional | |
Crane | Lifting capacity:4/5T; Articulated boom or Telescopic boom optional | |
Crane Technical Parameters:
Optional Crane Model | SQ4SK3Q | SQ5SK3Q | Unit |
Max Lifting Moment | 10 | 12.5 | t.m |
Max Lifting Capacity | 4000 | 5000 | kg |
Recommend Power Needed At Recommend Oil Flow | 16 | 18 | kw |
Max Oil Flow of Hydraulic System | 25 | 32 | L/min |
Rated Pressure Of Hydraulic System | 20 | 20 | MPa |
Oil Tank Capacity | 60 | 90 | L |
Rotation Angle | 360 all rotation | 360 all rotation | Degree |
Crane Weight | 1396 | 2215 | kg |
Installation Space | 850 | 900 | mm |
Pls find pictures as below for reference
