Dongfeng 6*4 crane truck for sale1>Rated lifting capacity: 10t
2>Base boom lifting height: 10.5m
3>Engine power: 230hp
Dongfeng 6*4 crane truck for sale
Crane truck | ||||||||
Vehicle Model | CLW5250JSQ3 | |||||||
Technical Parameter of Chassis | ||||||||
Chassis Model /Manufacturer | DFL1250A9/Dongfeng | |||||||
Overall Dimension | Length*Width*Height | mm | 11980*2500*3750 | |||||
Total Weight | Kg | 25000 | ||||||
Rated Payload | Kg | 9815 | ||||||
Kerb Weight | Kg | 14990 | ||||||
Front suspension/Rear suspension | 1460/3520 | |||||||
Engine | Model/Rated Power | ISDe230 30/230hp | ||||||
Emission Standard | Euro 3 | |||||||
Tire Type | 10.00-20,10.00R20,11.00-20,11.00R20 | |||||||
Driving type | 6*4 | |||||||
Wheel Base | mm | 5700+1300 | ||||||
Number of leaf spring | piece | 8/9 | ||||||
Max Speed | Km/h | 90 | ||||||
Technical Parameter of Crane | ||||||||
Lifting performance | Rated lifting capacity | t | 10 | |||||
Min. working radius | m | 5.176 | ||||||
Max. working radius | m | 14.142 | ||||||
Max. load moment | Base boom | KN.m | 1166 | |||||
Fully extended boom | kN.m | 645 | ||||||
Fully extended boom + Jib | kN.m | 475 | ||||||
Outrigger span | Longitudinal | m | 5.35 | |||||
Lateral | m | 6.0 | ||||||
Lifting height | Base boom | m | 10.5 | |||||
Fully extended boom | m | 33 | ||||||
Fully extended boom + Jib | m | 48 | ||||||
Working speed | Boom raising time | s | 80 | |||||
Boom full extension time | s | 100 | ||||||
Max. swing speed | r/min | 2.0 | ||||||
Hoist speed | Main winch | Full load | m/min | ≥85 | ||||
No load | m/min | ≥100 | ||||||
Aux. winch | Full load | m/min | ≥80 | |||||
No load | m/min | ≥100 | ||||||
Noise limit | Crane exterior noise | dB (A) | ≤118 | |||||
At seated position | dB (A) | ≤90 | ||||||
Payment terms and delivery:
Delivery date: 15 days
Payment terms: 30% TT as deposit and 70% TT upon receipt of B/L copy
Packing: nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
