Cement Mixer Truck With 12CBM Mixing Drum,mixer Truck

Cement Mixer Truck With 12CBM Mixing Drum,mixer Truck photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
CLW
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW5250GJBDFL
Weight 25000
Dimension(L*W*H) 9780*2500*3990
Certification ISO

Specifications

cement mixer truck with 12CBM mixing drum
-Italy reducer
-Germany hydraulic pumps
-Germany hydraulic motors
-with ISO

cement mixer truck with 12CBM mixing drum



Vechicle model

DFL5251GJBA1 Dongfeng cement mixer truck with 12 CBM mixing drum

Company name

HuBei ChengLi Special Automobile Co.Ltd

Vechicle size

mm

9780×2500×3990

Box size

××

F/R hang

1500/2930,1500/3130

Wheelbase

3800+1350,4000+1350

A/D angle



30/12,30/13

Total mass

Kg

24900

Rated mass

10770,10705

Curb weight

14000

Max speed

km/h

75

Chassis model

DFL5251GJBA1

Endine

Model

dCi340-30

Displacement

11120

Power

250

Fuel type

Diesel

alxes number

PC

3

Tyre number

PC

10

Tyre size

11.00-20,11.00R20

Axle load

 T

6970/17930 or 6950/17950 double alxes

Front track

mm

2027

Rear track

1820/1820,1850/1850

Hydraulic drive system

reducer

hydraulic pumps

hydraulic motors

radiators

tubing and other components.

Steel spring number

9/10,9/13

Other

Mixing tanker’s rated cubic meter is  8 cubic meter ,you can choose the Rearview mirror

Description

Cheng Li Dongfeng Automobile Dongfeng cement mixer truck with 12 CBM mixing drum Description:
Cheng Li Dongfeng Automobile Dongfeng cement mixer produced by Dongfeng factory chassis used in all production.
Also known as mixers cement mixer, cement truck, concrete mixer full name. Materials used in concrete transport, during transport to prevent the solidification of cement, it should be kept in the transport process of the rotation of tank mixing. General configuration of the system to take power from the engine, chassis, engine power and therefore have high requirements, the series of high-powered cars generally use a dedicated chassis production. Individual may be to install a small cement mixer engine to drive behind a mixing section.

Tanker

Tank from the Elliptical Head, the former body cone, cylinder and cone after the body of the four components, there are two spiral mixing blades, in vitro after the cone has a roller, cylindrical hole has opened a maintenance person .
    By the Deputy Vice-frame beams, front and rear supporting frame, roller, etc; lose material into the hopper by the a, a V-shaped slot and two U-shaped trough component output, charging and discharging to complete the task.
    The 12 CBM cement mixer truck vehicle control system for the flexible shaft type, through the manipulation of the handle of the pump operation can make reversing or stop by the handle on the throttle control can increase the throttle to accelerate, in the cab of the vehicle fitted with flexible shaft manipulation, and thus can be manipulated to achieve the car under the car
    Understand the wind and the cement mixer cement mixer sale price please contact Cheng Li company sales manager. We will provide you with detailed pictures and parameters of the cement mixer. In addition the company provides long-term concrete mixer parts sales.
