9m Standard Instructional Truck

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Transmission Type:

Manual

Emission Standard:

Euro 2

Chengli Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Transmission Type Manual

Emission Standard Euro 2

Fuel Type Diesel

Dimensions (L x W x H) (mm) 9000*2485*2650

Gross Vehicle Weight 13210

Place of Origin Hubei, China

Brand Name CLW

Model Number EQ1132FP4

Specifications

9m standard instructional truck
1,Dongfeng Chassis
2.Engine Power:Euro 2
3.Loading Capacity: 6500

9m standard instructional truck

Brand type	Dongfeng-brand EQ1132FP4-laden car (coach car)
Engine type	EQ6100-1(Gasoline engine environmental protection) LF6105QC(Liufa environmentally friendly diesel engine) YC4110QC(Yuchai Diesel environmental protection)
Rated power(KW)	99kw(135ps)
Shape size(mm)	9000×2485×2650(L×W×H)national standards
Fact cubage(mm)	6150×2294×550 (L×W×H)
Mass in working order(kg)	6515
GVW(kg)	13210
Rated loading capacity(kg)	6500
Clutch	325mm
Wheel base(mm)	5300
Tire specifications	9.00-20 12PR
Max speed(km/h)	90
Steering gear	Refers to the pin-worm
Driving room	The newest long single driving room
optional	Vice brake, rod shelf and rolling chair, high Railings, tarpaulin
others:our plant in accordance with user requirements of the users in the original old-fashioned standards of coaching based on the modified car, now converted into longer required by the national coach of nine-meter long car, modified car length as the country in line with the requirements of quality, cost at the end, Reduce unnecessary waste.
