28 Seats Passenger Trailer,open Wagon, Open Trailer

Suzhou Player Machinery & Equipment Manufacturing Co., Ltd.
28 Seats Passenger Trailer,open Wagon, Open Trailer thumbnail-1
28 Seats Passenger Trailer,open Wagon, Open Trailer thumbnail-2
28 Seats Passenger Trailer,open Wagon, Open Trailer thumbnail-3
28 Seats Passenger Trailer,open Wagon, Open Trailer thumbnail-4
28 Seats Passenger Trailer,open Wagon, Open Trailer thumbnail-5
28 Seats Passenger Trailer,open Wagon, Open Trailer photo-1
28 Seats Passenger Trailer,open Wagon, Open Trailer photo-2
28 Seats Passenger Trailer,open Wagon, Open Trailer photo-3
28 Seats Passenger Trailer,open Wagon, Open Trailer photo-4
28 Seats Passenger Trailer,open Wagon, Open Trailer photo-5
US$ 15,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Parts:
Trailer Plugs
OEM No.:
OEM Service Provided
Max Payload:
2100kg
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Parts Trailer Plugs
OEM No. OEM Service Provided
Max Payload 2100kg
Size 5375*1810*2410mm
Place of Origin Jiangsu, China
Brand Name SPL
Model Number PTC28
Product Description



Specification

L*W*H

5375*1810*2410mm

Weight

1480kg

Loading capacity

2100kg

Tread(front/rear)

1160 /1160mm

wheelbase

3795mm

Brake distance

≤4m

Passengers

28

Max. speed

25km/h

Max. climbing

20%

Min. ground clearance

180mm

Min. Turning Radius

7.5m

Car Body System

Seat

Artificial leather material +resilient PU;

Black, Gray, Cream-colored available

Chassis

Steel chassis,Power coating treatment

Body

FRP plastic

Dashboard

no

Rear view mirror

no

Lightning

E-mark approved Rear LED combination lights, inner LED light

Sound system

Japanese Pioneer Loudspeaker

Towing part

German Rockinger coupling

Floor

Bamboo + Aluminum plate

Chassis System

Steering system

all wheel steering system

Axle

Professional automobile axle

Suspension

Plate spring + cylinder hydraulic shock absorber

Brake

Pneumatic hydraulic converter for controlling wagon brakes. Pneumatic circuit for wagon braking.

Self-braking system in Emergency situation

Wheel

14x5 1/2J steel wheel

Tire

185R14C 8PR

Painting

Professional automobile painting






Product pictures
