Street legal 2 Electric golf cart with cargo box, CE approved, EG2048H EEC

Name: Street legal 2 Electric golf cart with cargo box, CE approved, EG2048H EEC
Price: Negotiable

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 2000 Unit / Units per Month

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Seats:	1 - 2	Fuel Type:	Electric	Battery Voltage:	48V
Certification:	EEC

Product Description

Street legal 2 Electric golf cart with cargo box, CE approved

---------EG2048H

Model	EG2048H
System	48V/5KW AC Sepex
Battery	8xT105(185Ah@5hr rate)
Motor	3.8KW Chinese motor
Controller	Curtis 1268 (400A@2minutes)

Dimensions
Overall dimensions (mm)	3430X1180X1800
Min. ground clearance (mm)	770x1100x250(mm)
Wheelbase (mm)	120
Front wheel tread (mm)	2450
Rear wheel tread (mm)	855

Electric system
Lighting system and horn	2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Charger	China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A

Steering and Suspension
Steering system	Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system	4-wheel hydraulic brake, front disc brake, rear drum brake
Accelerator	Stepless speed change
Suspension system	Front and rear plate spring + cylinder hydraulic shock absorber
Driving mode	Rear axle two stage deceleration, motor direct driving
Rear axle	Integrated, Gear ratio 12.76:1
Wheel & Tyre	10x6 Alumimum wheel & 205/50-10 4PR

Body and Frame
Frame	Welded steel framework with phosphate+electro-coating treatment
Body	PP plastic front body + PP plastic rear body
Roof	Injected plastic
Windshield	one-piece Organic glass
Large Seats:
1) backrest and cushion	Rebond seat + artificial leather
2) armrest	Formed
3) plastic seat bottom

Performance
Passenger capacity	4
Range (loaded) based on flat road at a speed of 20km/h (km)＊	>70
Max. speed @12.76:1 gear ratio	32
Minimum turning radius (m)	4.5
Max. climbing ability (loaded) @ 12.76:1 gear ratio	20%
Max. movement after brake at speed of 20km/h	≤4m
Max. loading weight	480kgs
Net weight	650kgs

Specifications

* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;

2) Range will vary depending on temperature, grade, payload and driving style.

Detailed Images

Packing & Delivery

Our most professional packaging

Transport of large trucks to the seaport

And international transport cooperation

Container loading qty	Assembled
20'ft GP	2units
40'ft GP	6units
40'HQ	6units
