Mini Hydraulic Full Electric Stacker Cranea. adjustable width double chain hooks
b. adjustable width four chain hooks
Mini Hydraulic Full Electric Stacker Crane (CE) VH-WCE
Description:
WCE series of floor crane is designed with adjustable length of straddle legs with large capacity but low price.
It is developed for used in workshop, maintainece and logistic area.
Working in workshop, you could use it to pick up and reposition of heave pieces of work, machine tools, chucks, steel bar/plate etc.
items be moved into and placed onto a bench or inside of a machine even it its flushed with the floor or the top cover.
The compact designed of crane is ergonomically be used in the tightest of spacees.
Propulsion:
1. Drive system: 24V/700W Series Wond motor with Microprocessor speed controler fully programmable
2. Hydraulic motor: 24V/2,000W
3. Battery: 2x12V/120Ah
4. Charger: 24V/15A
5. Run Speed: 4.0-5.0km/h
6. Overall size: 2010x1490x1570mm
Boom & capacity:
1. Boom Length : 1,200mm
2. Boom Extend: 600mm by hydraulic + 600mm by manual
3. Load Capacity: 1,200kgs boom retracted @ 1,200mm
600kgs single extended @ 1,800mm
300kgs double exteded @ 2,400mm
Assessories for Option:
. Remote control buttons ( 2.5M cable, 4 buttons )
. Wireless remote control
. Manual or power hoist
. Changable third boom with
a. adjustable width double chain hooks
b. adjustable width four chain hooks
c. drum clamp with rotator
This versatile and powerful units are built to handle continuous industrial use in repetitive lifting applications.
They offer additional productivity and ergonomic advantages over manual models, in addition to additional precision.
Units with capacities up to 1200kgs . lift and transport objects effortlessly.
Picture:
