Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Machinery Parts > API 7K TQ Series Casing/ Hydraulic Power Tong Sucker Rod Power Tubing Tong With Torque Gauge
API 7K TQ Series Casing/ Hydraulic Power Tong Sucker Rod Power Tubing Tong With Torque Gauge
US$ 1 - 10
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
kangyu
Model Number:
Customized
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2017 Hot Sale ! API 7K TOP Quality XYQ89/3YC Hydraulic Tubing Power Tong RS & TEDA BrandUS$ 1 - 10MOQ: 1 Set -
Top Selling !!! API Standard Drilling Tools Hydraulic Tubing Power Tong & Casing Power Tong & Workover TongUS$ 1 - 10MOQ: 1 Set
-
API 7K XQ Series Hydraulic Sucker Rod Power Tong for Small Casing & Tubing & Drilling PipeUS$ 1 - 10MOQ: 1 Set
-
API Diamond Core Bit for DrillingUS$ 50 - 500MOQ: 10 Pieces
-
Die Collar APIUS$ 399 - 699MOQ: 1 Piece
Place of Origin
Shandong, China
Brand Name
kangyu
Model Number
Customized
Machine Type
Other, Drilling Tool, Drilling Tool
Certification
Other, API, API
Material
Other, Carbon Steel, Carbon Steel
Processing Type
Other, Casting, Casting
Use
Well Drilling
Type
Other, Hydraulic Support
API 7K TQ Series Casing/ Hydraulic Power Tong Sucker Rod Power Tubing Tong with Torque Gauge
| Model | XYQ3B/3C | XYQ6B | XYQ12 | |
| Pipe size range of master tong | mm | 60~89 | 73~114 | 60~140 |
| in | 2-3/8”~3-1/2” | 2-7/8”~4-1/2” | 2-3/8”~5-1/2” | |
| Pipe size range of backup tong | mm | 60~114 | 89~141.5 | 73~156 |
| in | 2-3/8”~4-1/2” | 3-1/2”~5-1/8” | 2-7/8”~6-1/8” | |
| High gear rated torque | kN.m | 1.1 | 1.5 | 2.6 |
| Ibf.ft | 811 | 1106 | 1918 | |
| Low gear rated torque | kN.m | 3 | 6 | 13 |
| Ibf.ft | 2213 | 4425 | 9588 | |
| High gear rated speed | r/min | 100 | 85 | 68 |
| Low gear rated speed | r/min | 30 | 20 | 13 |
| Rated operation pressure | Mpa | 10 | 11 | 12 |
| psi | 1450 | 1595 | 1740 | |
| Maz.Flow | L/min | 80 | 100 | 120 |
| gpm | 21 | 26 | 32 | |
| Dimension | mm | 650*430*550 | 750*500*600 | 1042*582*839 |
| in | 25.6*16.9*21.7 | 29.5*19.7*23.6 | 41.0*22.9*33.0 | |
| Weight (including backup tong ) | kg | 158 | 220 | 471 |
| lb | 348 | 485 | 1038 | |
