Low Price 4M3 Self Loading Concrete Mixer Machine For Sale

US$ 35,000 - 45,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Model Number:

GNJB400

Xuzhou Silkway Machinery & Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Model Number GNJB400

Motor Power 6HP

Mixing Power Diesel Power

Charging Capacity 85-770L

Reclaiming capacity 4CBM

Speed of Mixing Drum 20r/min

Water Supply Mode Automatic Water Pump

Working Cycle Period 2-5min

Discharge Way Automatic

Outline Dimension 7.04*2.6 *3.4 m

After-sales Service Provided Engineers available to service machinery overseas

Low Price 4M3 Self Loading Concrete Mixer Machine For Sale

Product Description

Mixing System	Drum capacity of 6.1 cubic meters, the discharge opening height 1.8 meters
Production capacity	Concrete output: 4 m³/ cans, 12 m³ / h
Engine	Yuchai YC04122G, water-cooled, 4 cylinder / 4.836 litres, 85 kw / 2400 RPM
Engine	Xichai SDB075G, water-cooled, 4 cylinder / 4.836 litres, 85 kw / 2400 RPM
Transmission	Full hydraulic pressure drive, 4 wheel drive and two wheel steering, domestic axle
Walking speed	Low speed 9 km / h high-speed 20 km / h
Cab	Left-hand drive, anti-tilt, FOPS cab, front loading shovel
Hydraulic system	Domestic hydraulic systems, open loop for hydraulic transmission and drum rotation
Operating lever	Electronically controlled four-speed joystick
Bucket	700 liters, hydraulic valve
Chute	Hydraulic adjustable angle, in order to increase the discharge length
Water supply system	Hydraulically driven self-priming pump, washing with high pressure water pump vehicle, electronically controlled self-priming pump, take 2 * 400 water per minute
Brakes	Air brake brakes, dual independent circuits
Tire	Construction machinery tires 16/70-20
Power Systems	24V
Tank	Fuel tank: 218 liters, hydraulic tank: 218 liters
Weight	7100 kg
Dimensions	Length: 7.04 m Width: 2.6 m Height: 3.4 m
Measure	Electronic weighing, measuring water control, recipe controlled
