Overhead Lines Stringing Head Boards Two Bundle Conductor
Description
Two Bundled Conductors Stringing Head Boards Specifically designed to connect the pulling rope. Two types available: Two and three bundled conductors or four and five bundled conductors.
Technical Parameters
| Item Number | Model | Rated Load (kN) | Weight (kg) | Width of Applicable Sheave (mm) | Features |
| 17220 | SZ2-8 | 80 | 17 | 75 | Conductors are independent of each other. |
| 17221 | SZ2-8A | 19 | 100 | ||
| 17222 | SZ2-8B | 19.5 | 110 | ||
| 17223 | SZ2A-8 | 80 | 90 | 100 | Balanced pulley type |
| 17224 | SZ2B-13 | 130 | 55 | 110 | Conductors are independent of each other. |
| 17225 | SZ2C-13 | 130 | 50 | 110 | Conductors are independent of each other. |
| 17226 | SZ2B-18 | 180 | 90 | 125 | Conductors are independent of each other. |
Notice
If other specifications of pulleys are required to support our two bundle conductor stringing board, a clear indication should be given in the contract.
Please tell us the following information in your enquiry:
1. Quantity?
We'll give you a good price after confirming the above info.
Welcome to contact us by phone or e-mail, if you are interesting in our products.
