SA-YZ7.5 Winch Type Hydraulic Brake Tensioner for Stringing OPGW
US$ 3,000 - 4,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
XINYA
Model Number:
YL-7.5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
0.75 Ton Hydraulic ADSS OPGW Tensioner Stringing EquipmentUS$ 3,000 - 4,000MOQ: 1 Set -
SZ2B-13 13T Balancing Head Board Running Board for Two Bundle ConductorUS$ 250 - 800MOQ: 1 Piece
-
SZ4A-13 130KN Balancing Head Boards Running Board for Four Bundle ConductorsUS$ 250 - 800MOQ: 1 Piece
-
SZ3A-10 10T Balancing Head Boards Running Board for Three Bundle ConductorUS$ 250 - 800MOQ: 1 Piece
-
CXZ Series Cable Straightening Tools, Cable StraightenerUS$ 800 - 950MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
XINYA
Model Number
YL-7.5
Type
Other, Hydraulic Tensioner
SA-YZ7.5 Winch Type Hydraulic Brake Tensioner for Stringing OPGW
Essential parameter
| Model Type | SA-YZ7.5 |
| Overall Size(mm) | 2300*1250*1620 |
| Weight(kg) | 450 |
| Max Tension(KN) | 7.5 |
| Rated Tension(KN) | 5 |
| Max Velocity(m/min) | 40 |
| Diameter of Tension wheel(mm) | Φ1100 |
| Applicable Conductor Wire | ≤ LJ-240 |
| ≤ LJ-185/10 | |
| Suitable Hydraulic Oil Type | No.46 Antiwear Hydraulic Oil |
| Max Oil Temperature(°C) | 70 |
| Rated Working Pressure(MPa) | 25 |
Uses
It is used for stringing various conductors and earth wires.
Feature :
1. Adopt retarding with hydraulic pressure.
2. Light and convenient for line construction in mountainous area.
