3.5 Ton Hydraulic Puller Cable Pulling Machine
Application and Characteristic
1.It is applied to traction in the process of paying off the wire,earth wire,OPGW and ADSS.
2.Closed Hydraulic back oil circuit, bidirectional variable plunger pump ,you can change the traction in any case.
3.Maximum traction force can be preset, automatic overload protection.
4.Pressure loss automatic braking device is used to ensure the safety of system operation
when loss of pressure in case of the engine suddenly stops or other causes.
5.Hydraulic traction rope clamping device, automatic rope ,convenient to loading and unloading.
6. Trailer type structure,rigid scaffold,attractive appearance.
Quality Control
We have the complete production equipments and professional production team to manage the whole process from producing to packing and shipping.All of the products will be 100% tested before the delivery to ensure the quality of our products.
Our Values
1,Take First-Class Quality as Target and First-class Service.
2,As Responsibility, To Succeed By Scientific Management.
3,Customer in Heart, Quality in Hand, Technology in the Lead.
Technical Data for 3.5 Ton Hydraulic Puller Cable Pulling Machine
| Product NO. | 80023 | 80024 | 80025 |
| Type NO. | SA-YQ-35B | SA-YQ-55B | SA-YQ-80B |
| Maximum Tension(kn) | 35 | 55 | 80 |
| Continuous Tension(kn) | 30 | 50 | 60 |
| Maximum speed (m/min) | 80 | 85 | 95 |
| Bottom diameter of Drum(mm) | Φ320*2 | Φ460*2 | Φ540*2 |
| Number of grooves | 7 | 7 | 8 |
| Maximum suitable conductor diameter (mm) | Φ15 | Φ17 | Φ21 |
| Max connector | Φ40 | Φ52 | Φ65 |
| Dimensions (m) | 3.3*1.65*2.2 | 3.6*1.7*2.2 | 3.5*2.25*2.1 |
| weight(kg) | 1650 | 2200 |
4000 |
