CTE-25AS 700bar Single Acting Electric Hydraulic Pump
Use and Characteristics
Electric Hydraulic Pump CTE-25AS is a single-acting,double speed pump.It is used to provide pressurized oil to compatible tools: Cylinder, Crimping Head, Cutting Head, Busbar punching bending cutting tools, pipe bender etc. where 700 Bar (1000PSI) working pressure is required. Ram advancement and retraction are controlled by solenoid valve equipped inside.
Features:
Double Speed: For fast oil delivery
Single-Acting: Works with single acting remote control tool
Solenoid Valve euqipped: easily control ram advancment and retraction
PT3/8" Quick coupler: For quick connection with compatible tool
Technical specification below for your reference:
| Model | CTE-25AS |
| Flow Rate | Low Pressure:2.6L/Min High Pressure:0.32L/Min |
| Oil Capacity | 2.7L |
| Output | 1300W |
| Voltage | 220V/50Hz |
| Size | 230x160x390(mm) |
| Weight | 16 |
Different Type of Hydraulic electric Pumps
DYB-630A
| Model No. | DYB-630A | |
| High pressure | 70Mpa | |
| Low pressure | 7 Mpa | |
| High pressure oil flow | 0.6L/min | |
| Low pressure oil flow | 5.0L/min | |
| Power | 750W/220V/380V | |
| Frequency | 50Hz | |
| Rotation Rate | 1400r/min | |
| Oil tank | 7L | |
| Working | Manual valve control | |
DB150-D1
| Model No. | DB150-D1 | |
| High pressure | 70Mpa | |
| Low pressure | 7 Mpa | |
| High pressure oil flow | 1.7L/min | |
| Low pressure oil flow | 7.9L/min | |
| Power | 1500W/220V/380V/3.6A | |
| Frequency | 50Hz | |
| Rotation Rate | 1400r/min | |
| Oil tank | 30L | |
| Working | Foot control solenoid valve | |
ZCB-700B
| Model No. | ZCB-700B | |
| High pressure | 70Mpa | |
| Low pressure | 7 Mpa | |
| High pressure oil flow | 0.6L/min | |
| Low pressure oil flow | 5L/min | |
| Power | 750W/220V/380V/3.6A | |
| Frequency | 50Hz | |
| Rotation Rate | 1400r/min | |
| Oil tank | 7L | |
| Working | Foot control solenoid valve | |
ZCB-700B-2
| Model No. | ZCB-700B-2 | |
| High pressure | 70Mpa | |
| Low pressure | 7 Mpa | |
| High pressure oil flow | 0.6L/min | |
| Low pressure oil flow | 5L/min | |
| Power | 3000W/220V/380V/3.6A | |
| Frequency | 50Hz | |
| Rotation Rate | 1400r/min | |
| Oil tank | 30L | |
| Working | Foot control solenoid valve | |
JDB-160
| Model No. | JDB-160 | |
| High pressure | 70Mpa | |
| Low pressure | 7 Mpa | |
| High pressure oil flow | 1.7L/min | |
| Low pressure oil flow | 7.9L/min | |
| Power | 3000W/HONDA gasoline engine | |
| Rotation Rate | 1400r/min | |
| Oil tank | 18L | |
| Working | Manual valve control | |
Please tell us the following information in your enquiry:
1. Rating Press(Mpa) ?
2. Quantity?
we'll give you a good price after confirming the above info.
Welcome to contact us by phone or e-mail, if you are interesting in our products.
