Micro switch mechanical KW1-103-6
micro switch mechanical
A.With short roller lever,
B.SPDT 3PIN ON-(ON)
C.16A 125/250VAC
D.Certification:CE,CQC
Apply to microwave oven, air condition, electric cooker, dishwasher, cleaner, humidifier,water heater, electric radiator,e;ectric drill, joystick, TV game, time recorder, solder gun, mixer, food processor, juice maker, alarm, mixer, shredder machine, etc.
- The Main Thchnology Performane
Item | Value | |
Operating Speed | 0.1mm~1m/s(Related with actuator forms) | |
Operating Frequency | Mechanical 60 cycles/min;Electrical 30 cycles/min | |
Insulation Resistance | 100 MΩ (500VDC) | |
Contact resistance | <=30mΩ(Initial value) | |
Test Voltage | Between terminals of the same polarirty | AC1000V,50/60Hz,1min |
Between current-carrying metal And ground(case),and between Each terminal and non-carrying metal parts |
AC2000V,50/60Hz,1min | |
Vibration resistance | 10-55Hz,1.5mm Double amplitude | |
Shork Resistance | Destruction : OF>0.5N:1000m/s ²(approx.100G)max OF<=0.5N:500m/s ²(approx.50G)max Malfunction: OF>0.5N:300m/s ²(approx.30G)max OF<=0.5N:200m/s ²(approx.20G)max | |
Life Expectancy | Mechnical>=5000000 cycles Electrical>=50000 cycles | |
Degree of protection | IEC IP40 | |
Degree of protection against electric shock | Class I | |
PTI(Tracking Resistance) | 175 | |
Ambient air temperature | 125°C 60%RH below(No ice and dew) | |
Ambient air humidity | 85% Rhbelow(about +5~+35°C) | |
Weight | Approx.5.95g(No lever) | |
- Application
They are widely used in household appliances, electric force, telecommunications, machine tool, vessel, textile, printing, Mining machine, Mustic Instrument, etc.
- Others
Please kindly inform us which items you are interested, and the best price will be provided you upon receipt of your
new inquiry ASAP.
Any questions about more items, please feel free to contact us.
We are sincerely looking forward to establish cooperative relationship with you.
Free sample is available !
If you need any parts, please kindly send us your drawings or sample for quotation.
- PRODUCT SHOW
- CERTIFICATIONS
- PRODUCING DEPARTMENTS
Daier Electronics Co.,ltd is a professional manufacturer of electromechanical switches in Yueqing,China. Our factory covers an area of over 5,000 square meters, having a total staff of over 200 members. We are engaged in producing 9 categories and about 4,000 models of BNC connectors, push button switches, rocker switches, micro switches, touch switches, lift switches, refrigerator door switches, miniature toggle switches, indicators, alligators, fuse holders, signal lamps and etc. With a principle of being creative, advancedand honest, we are always improving our products and services to better satisfy you customers.
