6202Z original motor bearings
deep groove ball bearing
High Presion Low Noise Deep Groove Ball Bearing
| Product name | Deep Groove Ball Bearing 6202Z |
| bearing materials | GCr15/Chrome steel |
| Packing | 10pc in a small tube,5 tubes in a box; |
| Quality Certificate | ISO9001:2000, SGS,CE,ROSH,REACH |
| Feature | Low noise, less vibration, high precision and long life |
| ID*OD*W | 15x35x11mm |
| (mm) | |
| Basic static load capacity: | 7.65Cor(KN) |
| Basic dynamic load capacity: | 3.72Cr(KN) |
| Limiting Speed: | 18000 rpm (Grease lubricated); 22000 rpm (Oil lubricated); |
| Number of Ball: | 6 |
| style: | deep groove ball bearing |
| Net weight | 0.04KG |
| (kg) | |
| Brand name | TXIND, Offer OEM |
| MOQ | 100 sets |
| Port | Shanghai,tianjin,qingd0 |
| Payment Terms | L/C, T/T,paypal,western union etc |
| Service | OEM |
| Delivery period | 3-10 days |
| Tolerance level | ABEC-1 (P0), ABEC-3 (P6) |
| Seals type | ZZ,RS,open |
| Precision rating | P0, P6 |
| FOB Shenzhen/Shanghai | $0.1-2 |
| Antirust period | Bearings should normally be put under the protected condition then it is to be stored and preserved. The rustresisting period is two years. |
| Mining operations, paper mills, oil fields, marine industry, steel, electrical, construction machinery, various kinds of professional machinery and heavy industry of all types. | |
| Application | |
Description of deep groove ball bearing
Deep groove ball bearing is the most representative rolling bearing,it can suffer from both axial and
bidirectional radial load.It can be used in these occasions with the demand of high rotation,low noise, and low oscillation. Bearing with seal together with steel cover of rubber seal usually filled with lubricant in advance , the outside ring with stopping circle or flange, these will not only be easier for axial orientation, but also good for the installing of outside shell.The size of maximum loading bearing is just the same as standard bearing, while with backfill trough in the inside and outside, which can add the balls,and improve the maximum load at the same time.
Application of deep groove ball bearing
Deep groove ball bearing is mainly used in electrical motors, general machinery, industrial gearboxes, pumps, agricultural machinery, etc.
Package and Delivery of deep groove ball bearing
Package detail: Standard export packing or according to customers request.
Delivery detail: Within 3~7 days.
Our Advantages
1. More than 27 years bearing products manufacturing experience.
2. OEM order and non-standard bearing order accepted.
3. Various sizes of bearing are available.
4. Large stock and quick delivery.
5. Loading port is optional.
6. A certain number of free sample can be provided for test.
We can supply deep groove ball bearing:
|
Deep groove ball bearing (ZZ, 2RS ,NR,2RSH) |
604 series |
605 606 607 608 609 |
623 series |
623 624 625 626 627 628 629 |
|
634 series |
634 635 638 |
|
|
61800 series |
61800 61801 61802 61803 61804 61805 61806 61807 61808 61809 61820 61821 61822 61824 61826 61828 61834 61838 61840 61852 61860 61864 61872 61876 61880 61888 61892 |
|
|
61900 series |
61900 61901 61902 61903 61904 61905 61906 61907 61908 61909 61910 61911 61912 61913 61914 61915 61916 61917 61918 61919 61920 61921 61922 61924 61926 61928 61934 61936 61938 61940 61944 61948 61952 61960 61964 61968 61980 61984 61988 61992 |
|
|
16001 series |
16002 16003 16004 16005 16006 16007 16008 16009 16010 16011 16012 16013 16014 16015 16016 16017 16018 16019 16020 16021 16022 16024 16026 16028 16030 16032 16034 16038 16040 16052 |
|
|
6000 series |
6000 6001 6002 6003 6004 6005 6006 6007 6008 6009 6010 6011 6012 6013 6014 6015 6016 6017 6018 6019 6020 6021 6022 6024 6026 6028 6030 6032 6034 6036 6038 6040 6044 6048 6052 6056 6060 6064 6068 6072 6080 6088 6092 |
|
|
6200 series |
6200 6201 6202 6203 6204 6205 6206 6207 6208 6209 6210 6211 6212 6213 6214 6215 6216 6217 6218 6219 6220 6221 6222 6224 6226 6228 6230 6232 6234 6236 6238 6240 6244 6248 6252 |
|
|
6300 series |
6300 6301 6302 6303 6304 6305 66306 6307 6308 6309 6310 6311 6312 6313 6314 6315 6316 6317 6318 6319 6320 6321 6322 6324 6326 6328 63306332 6334 |
|
|
6403 series |
6403 6404 6405 6406 6407 6408 6409 6410 6411 6412 6413 6414 6415 6416 6417 6418 6419 6420 6422 6426 |
deep groove ball bearing 6312-2RS Reference Demensions
deep groove ball bearing
picture of deep groove ball bearing
Why us?
1. High accuracy
2. Low noise
3. Low weight
4. Can be customized according to your needs
5. Can provide small & miniature standard and non-standard ball bearings.
About Century Ruixin Transmission
Tianjin Century Ruixin Transmission Equipment Co,Ltd. is a manufacturer and global supplier of reliable ball & roller bearing & linear guide and ball screws solutions to target industries. the earliest factory is established in 1986, Investment to expand the new 16000 square meters factory in 2011, which collected the research and development manufacturing and sales.
The main business: bearing ,Non-standard bearings, tapered roller bearings, Inch tapered roller bearings,deep groove ball bearings, thrust ball bearings,spherical roller bearings,cylindrical roller bearings ,slewing bearings,pillow block bearings,ceramic bearings and needle roller bearings.
Bearing production flow chart
1. Payment:
1) TT, 30% deposit , 70% before shippment.
2) L/C at sight. (high bank charge, not suggest , but acceptable )
3) 100% Western Union in advance. (specially for air shipment or small amount)
2. Delivery :
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
- Your inquiry related to our product & price will be replied within 24 hours.
- Well-trained & experienced staff are to answer all your inquiries in English of course.
- Working time: 8:30am ~5:30pm, Monday to Saturday(UTC+8).
- OEM projects are highly welcomed. We have professional team here to help.
