XQ-2B metallographic specimen mounted machine
Applications and features:
XQ-2B metallographic specimen mounting machine (hereinafter referred to as embedded machine) is not suitable for surgery, is not easy to take a small sample metallurgical thermosetting plastics suppressed. Can be easily formed after grinding and polishing operations, but also conducive to the microstructure measured under microscope. Mounted machine under the following conditions to work reliably:
1, no more than 1000 meters above sea level;
2, the ambient temperature does not exceed +40 degrees Celsius, not the end in -10 degrees Celsius;
3, the air relative humidity less than 85% (at 20 degrees);
4, was no significant vibration and bumps;
5, no lead around the voltage of dust, explosive gases, and can seriously damage
Metal and insulation corrosive gases.
1, no more than 1000 meters above sea level;
2, the ambient temperature does not exceed +40 degrees Celsius, not the end in -10 degrees Celsius;
3, the air relative humidity less than 85% (at 20 degrees);
4, was no significant vibration and bumps;
5, no lead around the voltage of dust, explosive gases, and can seriously damage
Metal and insulation corrosive gases.
This machine is mechanically mounted, rotary hand wheel outside the body through a pair of bevel gear drive screw to suppress the body's lower die just die sample kit move up and down together with the heat due to plastic test specimen inlaid in like shape under heat conditions.Sample preparation process, forming a collective pressure exerted by the spring is fixed automatically compensated by the pressure of the sample pressed lights give instructions.
The mosaic configuration digital thermostat, enabling real-time temperature display and temperature independent settings, configure the timer, and in order to achieve a kind of semi-automated system, greatly improved work efficiency. Ideal specimen sample preparation time for each mosaic 8-10 minutes, will be smooth as a mirror
Product parameters:
Pressure test sample size: Ø22 × 15mm; Ø30 × 15mm; Ø45 × 18mm
Heater Specifications: 650W 220V
Temperature range :100-180 °C
Control Power: Voltage fluctuation is less than ± 15%, 220V, 50Hz
Dimensions: 340X270X400mm
Weight: 33KG
