Specifications
New HOWO 8 X 4 Drive breakdown lorry, wreker vehicle for sale1.hoist-lift associated
2.Max lifting weight 4.3ton
New HOWO 8 X 4 Drive breakdown lorry, wreker vehicle for sale
A tow truck (also called a wrecker, a breakdown truck, recovery truck or a breakdown lorry) is a vehicle used to transport motor vehicles to another location (generally a repair garage), or to recover vehicles which are no longer on a drivable surface.
Towing services are generally provided by an emergency road service operator. Vehicles are often towed in the case of breakdowns or collisions, or may be impounded for legal reasons.
1.Technical Features
I.Main specifications | ||||||||
Product model,name |
CLW5310TQZZ4 Wrecker Truck |
|||||||
Chassis Model |
ZZ1317N4337D1H |
|||||||
Curb weight(Kg) |
33000 |
Wheelbase(mm) |
1800+4575+1400 |
|||||
Tire specification |
12.00R20 |
Max speed(Km/h) |
80 |
|||||
Max grade ability (%) |
30 |
Type of fuel |
Diesel |
|||||
fuel consumption(L/100km) |
38 |
Max. lifting weight(kg) |
43000 |
|||||
Type of Upper part |
PFT50DZ3+PFT28TH+PFT50ZT3 |
|||||||
Emission standard |
Euro IV |
|||||||
Engine model |
Torque(N.m/r/min) |
Power(KW/r/min) |
||||||
D10.38-40 |
1560/1200-1500 |
276/2000 |
||||||
II. Lifting system | ||||||||
Max. lifting weight(ks) |
25000 |
Rating Lifting Mass Fully Extended(kg) |
8300 |
|||||
Extension Stroke(mm) |
1750 |
Max. Effective Length (mm) |
3650 |
|||||
Lift load folding Angle(°) |
-7~16 |
Folding Angle(°) |
-7~92 |
|||||
|
Fully extended crotch max distance from floor(mm) |
1835 |
|||||||
III.Hoisting system | ||||||||
Max. lifting weight(kg) |
30000 |
Max Full retract Lifting angle 30° capacity(kg) |
18000 |
|||||
|
Max Full extended Lifting angle 30° capacity(kg) |
7800 |
Boom length (mm) |
5880 |
|||||
Oil cylinder telescopic stroke(mm) |
6000 |
|||||||
Max Working Radius(mm) |
10710 |
Max lifting height (mm) |
12300 |
|||||
Boom Arms |
3 |
Boom luffing Angle(°) |
0~60 |
|||||
rotation angle(°) |
360 ratation |
|||||||
ch | ||||||||
Quantity(pcs) |
2 |
Rated traction Force(Kn) |
150 |
|||||
Wirerope specification |
20-6x25Fi+IWR1870 |
Wirerope OD(mm) |
¢20 |
|||||
Wirerope length(m) |
50 |
Min line velocity(m/min) |
5 |
|||||
IIV.Outrigger | ||||||||
Rating Pulling Power of Winch(kn) |
|
|||||||
Front outrigger type |
H-type |
Rear outrigger type |
L-type |
|||||
Front transverse span(mm) |
6600 |
Rear transverse span(mm) |
6600 |
|||||
Longitudinal span(mm) |
5550 |
|||||||
2.Product Show
