Hot!!!Dongfeng DFAC 4000 Liter Pesticide Truck

Name: Hot!!!Dongfeng DFAC 4000 Liter Pesticide Truck
Brand: Dongfeng
SKU: 140784198
Availability: InStock

US$ 13,000 - 22,000 MOQ: 1 Set

Key Specifications

Drive Wheel:

4x2

Fuel:

Diesel

Transmission Type:

Manual

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Usually Shanghai or any other ports in China as your request

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 4x2

Fuel Diesel

Transmission Type Manual

Condition New

Emission Standard Euro 3

Dimensions (L x W x H) (mm) 6470X1960X2450

Brand Name Dongfeng

Place of Origin Hubei, China

Model Number CLW5071GPS4

Gross Vehicle Weight 7300

Certification ISO9001,ISO14001 and CCC

Warranty One year since you get the truck and under the normal operation

After-sales Service Provided Overseas service center available

Hot!!!Dongfeng DFAC 4000 liter pesticide truck

Product Description

Technical Specifications

Main specifications of vehicle
Product model,name	CLW5071GPS4 pesticide truck
Total weight(Kg)	7300	Tank capacity (m3)	4
Payload (Kg)	3,815	Overall dimension (mm)	6470×1960×2450
Curb weight(Kg)	3355	Front/rear hang(mm)	1032/2138
cab seats (man)	2,3	Wheelbase(mm)	3300
Approach/departure angle (°)	16/10	Max speed(Km/h)	90
Number of axles	2	Axle load(Kg)	2920/4380
Instruction:
The truck is equipped with a water suction pump and an independent diesel generator which provides power for the spraying machine and pesticide pump.Flow of pesticide pump: 25-29L/min, Fog range: 50-150um, spraying range: vertical 20-25m, horizontal 30-40m, pitching angle: -10 ° -90 ° (remote control), spraying machine level rotating angle: 360 ° degree



Function:
The vehicle is used for disease and pest control in agriculture and forestry,and other tall forest trees.
Chassis specifications
Chassis model	DFA1070SJ35D6
Brand name	Dongfeng	Manufacturer	Dongfeng Motor Group Coo.,Ltd
Overall dimension(mm)	5845×1900×2220	Tires No.	6+1 (spare type)
Approach/departure angle (°)	19/16	Tire specification	7.00-16 14PR
Type of fuel	Diesel	Front track(mm)	1506
		Rear track(mm)	1466
Emission standard	GB3847-2005,GB17691-2005Euro Ⅲ
Chassis model	Engine manufacturer	Displacement(ml)	Power(Kw)
CY4102-CE4F	DongFeng Chaoyang Diesel Co.,Ltd	3856	73

Packaging & Shipping

1.About the package of our trucks,usually it is nude that covered with wax.And it also can be packed

as your need.

2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing/

SKD / etc. And it can be offered according to your request.

A.Delivery time
Usually within 10 to 25 days after getting your deposit. And the accurate time depends on your QTY.
B.Terms of payment
30% of contract amount must be paid by T/T before the production. After the completed trucks are checked and confirmed well by our clients, the balance shall be paid before the shipment.
C.Truck warranty to solve our clients’ worries when purchasing
The warranty period is one year or 25000KM that drove under normal operation and control since our clients get the trucks. And we can supply maintenance for the whole life.
