3 axles semi trailer truck,low bed semi trailer,milk transport semi trailer
- 100 Set / Sets per Month
- any port in China
- T/T
- Sedan SUV transport semi-trailer export semi-trailer Russian European style semi-trailer
- Low flatbed semi-trailer Hydraulic ladder semi-trailer Automatic low flatbed export trade
- Exporting trailers to Russia European style car transport Semi trailer price
- Multi axles modular low bed semi trailer
- AUTONE wingspan van semitrailer
- Container Semi Trailers
Product Details
Type: | Semi-Trailer | Material: | Steel | Certification: | Other, ISO |
Size: | 12990*2500*3900 | Max Payload: | 40000 | Place of Origin: | Hubei, China |
Brand Name: | CLW | Model Number: | CLW9403GYY |
Product Description
3 axles semi trailer truck,low bed semi trailer,milk transport semi trailer
carbon steel ,stainless steel can choose
manufacturer directly sale
Feature& Fuction
It takes advantage of compression resistant tank for transporting and laying up the liquefied , which is the special-purpose vehicles(For example propane ,
propylene, liquid ammonia, liguid nitrogen, liquid hydrogen, liquefied netural gas , liquid state sulphur dioxide and so on ).
Tank shaped use the advanced welding technology, end socket arc butt welding, and the once-forming of composite steel-plastic technology. Equipped with
active and passive safety devices to meet an emergency and can load and unload the material in long distance and completely close condition. Be applied to
transport varied oil, feul and chemical material, such as natural gas, liquefied petroleum gas, liquefied ammonia, carbon bisulfide, epoxy ethane, gas, butane,
dimethylmethane, propylene, etc. Cross section of tank could be oval, round and round-square. heat insulation and heating device is optional.
Specifications
Product model,name | CLW9403GYY transportation semi-trailer truck(transportation media:Fuel) | ||
Total weight(Kg) | 40000 | Tank capacity(m3) | 50.5 |
Payload (Kg) | 32830 | Overall dimension(mm) | 13000×2500×3977 |
Curb weight(Kg) | 7170 | Tank size(mm) | inner diameter×wall thickness×length:2470×12×12840 |
Tank material | Q345R | Design pressure(Mpa) | 1.61 |
Design temperature(°C) | 50 | Filling capacity per unit(t/m3) | 0.42 |
Tank corrosion allowance(mm) | 1 | Axle load(Kg) | -/24000(three axles) |
Approach/departure angle (°) | -/16 | Front/rear hang(mm) | -/1870 |
Steel spring number | -/7/7/7 | Tractor | 90# |
Number of axles | 3 | wheelbase(mm) | 7200+1310+1310 |
Tires No. | 12 | Tire specification | 11.00R20 12PR |
ABS | yes | Rear track(mm) | 1840/1840/1840 |
Configuration instructions | Single out the liquid,doulbe side loading and discharge,Double valve boxes,single tool box,safety valve,thermometer,pressure gauge,emergency shut-off valves,fire extinguisher , anti-static grounding tape. |
For more information,please feel free to contact me! We will do our best to work with you to get the job done.
Contact person :
Tiffany Sheng (overseas sales)
Hubei Chengli Ocean Auto Sales Co.,Ltd
ADD: Capital of Special Purpose Vehicle, Suizhou City, Hubei Province,China.
Web: /www.clyyqc.en.china.cn
Tel: +86-13886865927 / +86-722-3819709
Fax: +86-722-3819809
Skype:Tiffany shen
Wechat ID:(0086)13886865927
QQ ID:3305501273
