3 Alxes 40000 Liters Milk Transportation Semi Trailer Truck

US$ 20,000 - 50,000 MOQ: 1 Unit

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Other, ISO 9001-2008 CCC

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in china

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification Other, ISO 9001-2008 CCC

Size 12600*2500*3850

Max Payload 31800kg

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW9400GNY

3 alxes 40000 liters Milk transportation semi trailer truck
6mm tank thickness
ISO9001:2008

tractor can offer

1.The tank liner is made of high quality food grade stainless steel and the inner tank has been fine polished.

2.Equipped wih PIC cleaning devices.

3.With function of thermal insulution:medium termperature change ≤1 °C durning 24 hours.

4.The tank can be divided into several parts according to demand to load different materials.

Specifications

Main specifications
Product model,name	CLW9400GNY Milk Transportation Semi-trailer Truck
Total weight(Kg)	40000	Tank capacity(m3)	40.7
Payload (Kg)	31800	Overall dimension(mm)	12600×2500×3850
Curb weight(Kg)	8200	Steel spring number	-/8/8/8,-/4/4/4
Approach/departure angle (°)	-/12	Front/rear hang(mm)	-/1630
Number of axles	3	wheelbase(mm)	6850+1310+1310
Tires No.	12	Tire specification	11.00-20 12PR,11.00R20
Axle load(Kg)	-/24000(three axles)	Rear track(mm)	1840/1840/1840
instruction	transportation media:milk ,density:0.82 T/CBM,Tank effective capacity :40.7cbm;tank overall dimension(length/long axis /short axis)(mm):12240/2480/2110(practical size 12080/2320/1950,thickness of insulating layer outside the tank 80mm).
