Dongfeng Kingrun 10ton refrigerated van truck

Main specification

Product model and name

CLW5160XLC3 Refrigerator truck

Gross weight(Kg)

16000

Drive type

4x2

Payload(Kg)

9000

Overall dimension(mm)

9990X2490X3850

Curb weight(Kg)

6805

Cab seats

3

Approach/departure angle(°)

20/8

Front/rear hang(mm)

1430/2960

Axle No.

2

Wheelbase(mm)

5600

Axle load(Kg)

6000/10000

Max speed(Km/h)

90

Chassis specification

Chassis model

DFL5160XXYBX1

Manufacturer

Donfeng Motor Co.,Ltd

Brand name

Dongfeng

Dimension(mm)

9790×2370×2760,2640

Tyre specification

10.00R20

Tyre No.

6

Steel spring number

7/9+6

Front track base(mm)

1880

Fuel type

Diesel

Rear track base(mm)

1800,1860

Emission standard

Euro 3

Transmission

6 forward gear,1 reverse gear

Cab

Single row, luxurious interiors and seats with power steering.

Air condition is optional.

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

B190 33

Dongfeng Cummins Engine Co.,Ltd

5900

140(190HP)

Performance

Van body size

7400X2280X2400

Load capacity(TON)

10

Lowest refrigeration temperature(℃)

-18 Centigrade

Temperature range

-18 to -5

Feature and Application

The refrigerator truck is the closed van truck that is used to transport the frozen or fresh goods. This truck is made up of vehicle chassis, Polyurethane insulation van, refrigeration unit and temperature recorder. It is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc. parts can be chosen and installed.
