New Factory Selling Chengli Roll on Roll off Garbage Truck

Hubei Ocean Special Automobile Co., Ltd.

US$ 9,000 - 29,000 MOQ: 1 Set

Key Specifications

Drive Wheel:

6x4

Capacity (Load):

11 - 20t

Horsepower:

150 - 250hp

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 6x4

Capacity (Load) 11 - 20t

Horsepower 150 - 250hp

Condition New

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 4 - 6L

Gross Vehicle Weight 9795

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW3200 roll on roll off garbage truck

Dimensions (L x W x H) (mm) 7800,7900*2500*3100

New factory selling chengli roll on roll off garbage truck

Product Description

cummins engine, 20 ton capacity

bottom plate is 8mm thickness,side plate is 6 mm,Many choices

Rmarks: The information above is just for your reference. We can manufacture trucks according to your demands.

Main Specification

Vehicle model	CLW3200 roll on roll off garbage truck	Batch No.	208
Manufacturer	Hubei Chengli Special automobile Co. ,Ltd(china)	Brand name	CLW
Overall dimension(mm)	7800,7900×2500×3100	Total weight(Kg)	14900
Body internal dimension(mm)	4750,5300×2300×1050	Rating load(Kg)	6070
Approach/departure angle	32/18	Curb weight(Kg)	8380
Front/rear hang(mm)	1245/1655,1245/1755	Max speed(km/h)	85
Chassis model	EQ3208VPJ3
Engine model	Engine manufacturer	Emission	Power
ISDe210 30	Dongfeng Cummins engine company	6700	155
Fuel type	Diesel	Emission standard	EGR
Axle number	3	Tyre number	10
Wheelbase	3600+1300	Tyre specification	10.00-20,11.00-20,10.00R20,11.00R20
Axle load	5600/14890	Front wheel distance	1940
Leaf spring number	8/13	Rear wheel distance	1860/1860
