FAW 10ton low flatbed trucks 4x2 low bed truck with reasonable price
1>max load capacity:10tons
2>drive type:4*2
| Main specifications | |||
| Product model,name | CLW5161TPBC3 Flatbed Truck | Bearing platform length | 5800 |
| Total weight(Kg) | 15900 | Overall dimension (mm) | 9000×2490×3000 |
| Payload (Kg) | 9000 | Transmission: | 5 forward gear, 1 reverse gear |
| Curb weight(Kg) | 6705 | Front/rear hang(mm) | 1312/2418, 1312/2338 |
| cab seats (man) | 3 | Wheelbase(mm) | 5270, 5350 |
| Approach/departure angle (°) | 21/7 | Max speed(Km/h) | 90 |
| Number of axles | 2 | Axle load(Kg) | 5900/10000 |
| Chassis specifications | |||
| Chassis model | CA1168PK2L2EA80 | ||
| Brand name | FAW | Manufacturer | FAW Qingdao Automobile Co., Ltd. |
| Overall dimension(mm) | 8282,8832×2290×2630 | Tires No. | 6+1(spare tire) |
| Approach/departure angle (°) | 21/13 ,21/11 | Tire specification | 8.25-20,8.25R20 |
| Type of fuel | Diesel | Front track(mm) | 1800 |
| Drive type | 4x2 | Rear track(mm) | 1800., 1740 |
| Emission standard | GB3847-2005,GB17691-2005Euro Ⅲ | ||
| Chassis model | Engine manufacture | Displacement(ml) | Power(Kw) |
| CA4DF3-13E3 | FAW Car Co. Ltd. of Wuxi Diesel Engine Factory | 4752 | 101 |
3. Quality:
The above goods shall be in accordance with the Manufacturer’s standards and Chinese export standards.
4.TIME OF DELIVERY:
Within 20-25 working days from the receipt date of deposit payment.
5.GUARANTEE PERIOD
The guarantee period for all equipment/accessories and spare parts shall be valid 12 months from Shipment or 10000klm..
6.Terms of Payment:
30% of the contract value should be paidin advance, remaining 70% payment shall be paid upon notification of completion and inspection certificate.
7.Packing and shipping
(1) About the package of our trucks,usually it is nude that covered with wax. And it also can be packed as your need.
(2) About the shipping,there are many ways, such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
