Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck

Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-1
Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-2
Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-3
Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-4
Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-5
Dongfeng 6x4 Euro 4 13 Ton Flatbed Tow Body Truck photo-6
US$ 36,700 - 40,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Emission Standard:
Euro 4
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Fuel Type Diesel
Emission Standard Euro 4
Condition New
Transmission Type Manual
Dimensions (L x W x H) (mm) 10450x2500x3110 mm
Place of Origin Hubei, China
Brand Name Dongfeng
Model Number CLW5250TPBT4

Dongfeng 6x4 euro 4 13 ton flatbed tow body truck



Product Description

  Flatbed truck, also called construction machinery transportation truck, flat bed truck,flat deck truck, tow truck, is mainly used to transport some machines like excavators, loaders, harvester and other combined and non-removable objects. Flat bed truck is common in life, widely used in factories, construction and other large-scale production or project.The bearing capacity of the truck is very strong, making it played an important role in the process of economic development. It can suitable for all kinds of road conditions.

Main specification



 1.Technical Specification



[Main specifications]

Product model,name

CLW5250TPBT4 Flatbed truck

Gross vehicle weight(kg)

24900

Drive type

6x4

Payload(kg)

13505

Overall dimension (mm)

10450×2500×3110

Curb weight(Kg)

11200

cab seats (man)

3

Approach/departure angle (°)

23/6

Front/rear hang(mm)

1250/3150

Number of axles

3

Wheelbase(mm)

4750+1300

Axle load(Kg)

7000/17900

Max speed(Km/h)

85

Loading bearing surface dimension(L*W mm)

7300×2500

[Chassis specifications]

Chassis model

EQ1258VFJ1

Manufacturer

Dongfeng Motor

Corporation

Brand name

Dongfeng

Overall dimension (mm)

11700×2470×2850

Tire specification

10.00-20

Tires No.

10

Steel spring number

9/10

Front track(mm)

1960

Fuel type

Diesel

Rear track(mm)

1860/1860

Emission standard

Euro IV

Transmission

8 gears

Cabin

New design D913 flat cab, luxurious interior trim and seat, sleeper. air conditioning can be equipped if customer requirement.

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

YC6A240-46

Guangxi yuchai

machinery co., LTD

7255

177

[Functions]

Mainly used for transport for excavator, wheel loader, harvest ect undisassemble machines.







Product Overviews

 Dongfeng 6x4 euro 4 13 ton flatbed tow body truckDongfeng 6x4 euro 4 13 ton flatbed tow body truckDongfeng 6x4 euro 4 13 ton flatbed tow body truckDongfeng 6x4 euro 4 13 ton flatbed tow body truckDongfeng 6x4 euro 4 13 ton flatbed tow body truckDongfeng 6x4 euro 4 13 ton flatbed tow body truck

Company Information

Dongfeng 6x4 euro 4 13 ton flatbed tow body truck

Dongfeng 6x4 euro 4 13 ton flatbed tow body truck

Dongfeng 6x4 euro 4 13 ton flatbed tow body truck

Dongfeng 6x4 euro 4 13 ton flatbed tow body truck

Our Services

  3.Quality

 The above goods shall be in accordance with the Manufacturer’s standards and Chinese export standards.



4.TIME OF DELIVERY

 Within 10-25 working days from the receipt date of deposit payment.



5.GUARANTEE PERIOD

 The guarantee period for all equipment/accessories and spare parts shall be valid 12 months from Shipment date or 10000klm.



6.Packing and shipping

 (1) About the package of our trucks,usually it is nude that covered with wax. And it also can be packed as your need.



 (2)About the shipping,there are many ways, such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.





7.Terms of Payment:



 30% of the contract value should be paidin advance, remaining 70% payment shall be paid upon notification of completion and inspection certificate.
