kapasiteye 12m3 beton mikser kamyonu, mikser kamyonu
Our Company
concrete truck mixer truck
Concrete trucks mixer trucks are made to transport and mix concrete up to the construction site. They can be charged with dry materials and water, with the mixing occurring during transport. With this process, the material has already been mixing. The concrete mixing transport truck maintains the material's liquid state through agitation, or turning of the drum, until delivery.
Main specifications | ||||
Product model,name |
SX5255GJBJR404 Concrete mixer truck |
|||
Gross weight(Kg) |
25000 |
Drive type |
6 x 4 |
|
Payload(Kg) |
11170 |
Overall demension(mm) |
9995×2500×3985 |
|
Curb weight(Kg) |
13700 |
Cab seats(man) |
2,3 |
|
Approach/departure angle(°) |
20/19 |
Front/rear hang(mm) |
1525/3095 |
|
Number of axles |
3 |
Wheelbase(mm) |
4000+1350 |
|
Axle load(Kg) |
7000/18000 |
Max speed(Km/h) |
77 |
|
Chassis specifications | ||||
Chassis model |
SX5255GJBJR404 |
Manufacture |
Shaanxi Automobile Group Co., Ltd. |
|
Brand name |
SHACMAN |
Overall dimension(mm) |
8660×2495×3270 |
|
Tire specification |
12.00R20 |
Tires No. |
10 |
|
Steel spring number |
9/12,10/12 |
Front track(mm) |
2036 |
|
Fuel type |
Diesel |
Rear track(mm) |
1850 |
|
Emission standard |
Euro III |
Transmission |
9 forward gear |
|
Cabin |
Luxury interior and Instrument bar, with air conditioning and sleeper. |
|||
Main engine model |
Engine manufacutre |
Displacement(ml) |
Power(kw) |
|
WP10.340E32 |
Weichai Power Co., Ltd |
9726 |
250 |
|
Concrete mixer truck performance | ||||
Tank volume(m3) |
12 |
Material of tank |
Q345 |
|
Pump |
Import |
Motor |
Import |
|
Reducer |
Import |
Surplus ratio |
≤1.0% |
|
Water tank volume(L) |
350L |
The supplied water method |
Pneumatic |
|
Concrete mixer truck features | ||||
This is mainly used for the modern roads and major construction projects, which is for ensure the quality of the concrete poured by stirring the concrete slowly and continuously during transporting or one the construction site. | ||||
