Loader Segment Cutting Edge 3g6395 With Material 27MnTiB 30MnB

Name: Loader Segment Cutting Edge 3g6395 With Material 27MnTiB 30MnB
Brand: Higher Blades
SKU: 140780314
Availability: InStock

Jinan Higher Blades Co., Ltd.

Negotiable MOQ: 10 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Higher Blades

Model Number:

3g6395

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port to delivery loader segment cutting edge with material 27MnTiB 30MnB

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Higher Blades

Model Number 3g6395

loader segment cutting edge with material 27MnTiB 30MnB

MANUFACTURER,OEM,EXPERIENCE,CONSISTENCE QUANLITY

1. OEM part number 8E4193/ 8E4194, 8E4198/8E4199, 9W1875/ 9W1876,

3G8319/3G8320,9W8874/9W8875, 175-71-22272/175-71-22282, 195-71-11173/195-71-11183 , 175-70-21136/175-70-21126 , 140-70-11170 /140-70-11180......

2. Material:27MnTiB and 30MnB Boron steel both with heattreatment. Q550D-T ,C45,C80...

3. Hardness:HB320~360 or HB440~480.

5.Thickness from 16mm to 60mm.

6. Different type: Level end bits and Hot cupped end bits

7. Available to all brand bulldozer domestic and overseas especially for Caterpillar and Komatsu.

Materials	Hardness (HB)	Yielding Strength(MPa)	Tensile Strength(MPa)	Elongation (%)	Impact Energy (J)
HM360	330-390	≥800	≥1000	≥16	≥40(-20℃ KV)
HM400	370-430	≥1050	≥1250	≥12	≥25(-20℃ KV)
HM450	430-470	≥1150	≥1300	≥10	≥50(25℃ KU)
HM500	470-520	≥1250	≥1450	≥7	≥40(25℃ KU)
HM550	530-570	≥1300	≥1550	≥5	≥20(25℃ KU)
HC80	250-330	≥450	≥900	≥11	≥15(25℃ KU)
HC45	Specification is adjusted by the technical requirement
