Pole drilling machine on tractor with crane for Highway Bridgg Company
Introduction of pole drilling machine
pole drilling machine is a machine who can digging hole,
hanging up the wire rod and bury all alone. One person opera and one help to fix the wire rod. Save manpower
and with high efficiency.easy working on The loess layer, clay layer, containing pebbles gravel soil, weathered
rock and soil, frozen soil, building garbage, backfill sand, garbage layer.
|
1/power: 100HP. 73.5KE four wheel tractor 2/The drilling depth: 0 m -6 M 3/Bore diameter: 0mm-1200mm 4/ Spiral drill hydraulic drive form: hydraulic hoist 5/Standard bar pit time: 40 seconds (500mm in diameter x depth 3M) 6/operate:one driver 7/ Approved:CE,ISO9001,ISO9002,SGS 8/Net/Gross Weight: 6.68t/6.8t 9/Package Dimension:full 20 feet container 10/color:yellow and green 11/Working principle: screw be pushed by power from hydraulic. |
|
Features of pole drilling machine
pole drilling machine is with hydraulic ,so it working well and more easy, also save power, can working
in the place where is no electric power. Can be widely used in hard soil frozen and containing gravel area.
Can making hole for 300-1200mm. Deep at 1000-6000mm. professional design of drill can digging more quickly, also work well on The soil containing pebbles.
Vertical a pole include transport it ,digging hole, vertical it, bury it. normal way for pole vertical need people help, 10 people can vertical a wire rod in 2 hours.
Working principle of tractor crane
Unit structure of tractor crane with 50 horsepower tractor as power, a hydraulic pump, distributor drive the
speed reducer and drill pipe work, simple operation, strong off-road capability.
tractor is the power, lead machine working, hydraulic system control drill working, can give out high puch on drill, digging hole at deepth <6000mm, diameter of the drill can be changed.
new design ,add 2 more box rion on the arm of digger, so it can be more stable in digging.
Spare parts of tractor crane
Factory Introduction:
Gongyi Dahai machinery plantwas built up in 1980 and have been casting of machines for 30 years , covering an
area of about 20000 square meters.hydraulic digging machine is the main part deisgn by Dahai Pan ,who have been invite to the CCTV show I love the invention. be well knowen at his well use of hydraulic system.
Transport:
A single machine can be loading in a full 20 feet container, 2 sets need a full 40 feet container. machine can be drive into container directly.
Customers can come to our factory testing the machines and also can learn operate machine with the help of our drivers. welcome everybody!
In order to order the suitable product,you need to make sure the following details:
application→drilling depth→drilling caliber→stratum
