Home > Products > HAY RAKE > Tractor wheel hayrake 8 discs hay rakes farm,Colter regulating lever,plough point for agricultural machines
Tractor wheel hayrake 8 discs hay rakes farm,Colter regulating lever,plough point for agricultural machines
- 200 Unit / Units per Month
- Qingdao
- T/T Credit Card
Product Details
Type: | Hydraulic hay rake with wheels | Use: | Collecting grass,Hay rake and tedder | Certification: | ISO,CE |
Place of Origin: | Shandong, China | Brand Name: | Longtao | Model Number: | 9LZ-4.8 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Tractor wheel hayrake 8 discs hay rakes farm,Colter regulating lever,plough point for agricultural machines
Features:
9LZ series hydraulic disk rake using the latest design style, the wheeled tractor traction, working parts to take tine refers to the plate, the machine by referring to disc in order to the latter refers to the plate, until form a loose, ventilation article grass. Change refers to the Angle of plate or to adjust the width of article grass. Long tine for spring steel teeth, sturdy and durable, can independently effect is good, copying performance is strong. With tension spring to control the pressure refers to the plate on the ground, can according to crops and ground conditions, through the tensile adjustment plate adjustment ground pressure. This machine has simple structure, convenient operation, the use of reliable, less failure, high efficiency, operation quality. Maintenance is simple, dynamic performance is good. Transportation can hug plate of hoisting, will use the tire walk, equipment can adjust, can independently to the width of the ease of use.
Parameters:
Model | 9LZ-3 | 9LZ-4 | 9LZ-4.8 |
Dimension(m)(L×W×H) | 2.3×3.6×1.5 | 2.8×4.9×1.5 | 3.6×5.3×1.5 |
Weight(kg) | 160 | 300 | 360 |
Working speed(km/h) | 5 | 10 | 15 |
productivity(h/h) | 1 | 1.5-3.5 | 3-5 |
working width(m) | 3 | 4 | 4.8 |
No. of rake plate | 4 | 6 | 8 |
Plate diameter(m) | 1.46 | 1.46 | 1.46 |
No of teeth for each rake plate(pc) | 80 | 80 | 80 |
Missing rate | 1 | 1 | 1 |
swath width(m) | 1-1.5 | 1-1.5 | 1-1.5 |
Matched powered | 20-40hp | 30-50hp | 40-75hp |
Linkage | Rear 3 point linkage or trailed | ||
Equipment width during transport(m) | 3.2 | 3.2 | 3.2 |
Equipment height during transport(m) | 3 | 4.3 | 5 |
- Longtao offer third party inspection service such as B.V, SGS, COI etc.
- OEM accepeted, customized available.
- Sample available, engineer overseas available for wholesaler.
- Warranty: 24 months warranty, if problem caused by quality factor, we will send you free spar e parts by air within one week
- Delivery time: we deliver within 7-10 days after getting deposit.
- Dealership: We search for long-term dealership, price and quality are good, enough spare parts can be provided.
- Third party: Each machine was tested before shipping, we allow third-party (such as BV, SGS, COI etc.) to test the machine and factory before shipping.
- We accept FOB, CIF, CNF, DDU & DDP. we can help shipping.
- CE, ISO approved.
Established in 1998, and changed to existing name in 2002, Weifang Longtao Machinery is a professional manufacturer engaged in development, production, sale and service of mining machinery, farm machinery and mechanical machining.
Our main products include underground mining loader, underground transport trucks,mining drilling rig rock breaker,hay baler,lawn mower,tractor front loader with backhoe,wood chippers, power tillers, farm tools and varieties, etc. The annual output amounts to 150,000 units. We also do processing with sample, drawings or materials supplied, and OEM orders are welcome
1.Does the hay rake comes with the tractor?
We usally quote price of hay rake,not including tractor,if you want tractor,we can quote you seperately.
2.The working width of hay rakes?
we have 3000 mm,4000 mm,4800 MM working width hay rake.
3.The plates of the hay rake?
4 pcs,6 pcs,8 pcs
4.The hay rake linkage?
Rear 3 point linkage or trailed
5.How to order?
After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for the deposit. For single set, your machine can be ready within 7 days after we getting the deposit, we will send to the port and deliver to you by sea.
-In case for more handing charges, you can transfer 100% of the payment, we can arrange the products and shipping under your allowance.
-If you still don't understand, please don not hestitate to ask me.
