We are a factory of producing site dumpers, wheel loaders, tractors and other farm machines, all products especially for global export market with advanced design,
good quality parts and reasonable price;
Pls contact Mr david 86-15318957289
and you are welcomed to vist our factory any time.
Specifications
*CE/ISO9001:2008 wheel loader with Deutz/cummins engine
*WEICHAI Engine or Cummins engine
*Floating position valve
Specifications
Specification |
overall weight(kg) |
9500 |
L×W×H(mm) |
7050×2430X3120 |
|
rated bucket capacity(m3) |
1.7 |
|
Rated load(kg) |
3000 |
|
Maximum dump height (mm) |
3020/3250 |
|
Bucket indicator |
Yes |
|
Max. breakout force(KN) |
138 |
|
Engine |
Model |
WEICHAI Deutz TD226B/Cummins 6BT5.9-C125 |
Type |
In line,direct injection,four-stroke,liquid cooled |
|
|
Rated power(kw) |
92kw |
|
Rated speed(r/min) |
2200 |
|
Transmission system |
Model of torque converter |
YJ320B |
Type |
single-phase single-stage radial-inward turbine triplex |
|
Gearbox type |
Fixed-spindle power shift |
|
Gear shift |
2 gears ahead,2 gear astern |
|
Hydraulic system |
Distribution of work valve |
DF25 |
Working pump |
CBGj2100,CBGq2100 |
|
Steering system |
Type |
Articulated hydraulic steering |
Max. turning angle |
lift and right 36.5±1° |
|
Min turning radius(mm) |
5862 |
|
Brake system |
Brake type |
air-break brake |
Tyres |
Standard tyres |
17.5-25 |
|
