Help CenterHot Selling 1.5ton Mini Wheel Loader ZL15/JT915, Small Wheel Loader With 1ton Capacity for Exporting
Related Products
-
China Used 3.0 Ton Wheel Loader, With Good Condition, Can be Renovated Before DeliveryUS$ 1 - 2MOQ: 1 Set -
China Factory Supply 800kg Compact Wheel Loader, ZL08F for Export Market, Small Wheel LoaderUS$ 1 - 2MOQ: 1 Set
-
China Factory Supply 1200kg Mini Wheel Loader With CEUS$ 1 - 2MOQ: 1 Set
-
1.0 Ton Mini Compact Wheel Loader For Sale, 0.5cbm,37KWUS$ 1 - 2MOQ: 1 Set
-
China 800kg ZL08F Wheel Loader With Yuchai/changchai Diesel EngineUS$ 1 - 2MOQ: 1 Set
| Specification | overall weight(kg) | 3600 |
| L×W×H(mm) | 4900×1830×2720 | |
| rated bucket capacity(m3) | 0.7 | |
| Rated load(kg) | 1500 | |
| Maximum dump height (mm) | 2750 | |
| Bucket indicator | Yes | |
| Max. breakout force(KN) | 43 | |
| Engine | Model | A498 BT1 EURO III |
| Type | In-line arrangement, Water cooling, four-stroke | |
| Rated power(kw) | 37kw/36.8KW | |
| Rated speed(r/min) | 2300 | |
| Transmission system | Model of torque converter | JINTAI |
| Type | Power shift, spur gear constantly in mesh | |
| Gearbox type | Fixed-spindle power shift | |
| Gear shift | 2 gears ahead,2 gear astern | |
| Steering system | Type | Articulated hydraulic steering |
| Max. turning angle | 30±1° | |
| Min turning radius(mm) | 3000 | |
| Brake system | Brake type | Oil brake(Vacuum booster) |
| Tyres | Standard tyres | 12-16.5 |
| Optional wide tyres | 14-17.5(vacuum) |
Advantage & Application
1.Chinese C-ummin-s intercooled& turbocharged diesel engine;
2. Integral torque converter and gearbox(Germany ZF technology);
3. Driving axle with built-in free-wheel anti-slip differential;
4. Heavy-duty roller chains transmission balance box;
5.Popular swing-arm connecting rod operating mechanism;
6. Free-maintenance rolling-disc rotary device;
7. Double cylinders control the balde cutting angle;
8.Two sets of imported control valve
9. Imported hydraulic balancing valve for the blade lifting;
10. Steering system:center articulated mechanism and tilting front wheels to achieve crab-style movement;
11. Electro-hydraulic control: instrumentation monitoring & maintenance-free OPTIMA battery;
Our Services
1.Reply your inquiry in 24 working hours.
2.Company is the professional manufacturer, who carries an extensive range of new heavy duty equipments and agricultural machinery, such as wheel loaders, site dumpers, wheel excavators, tractors, and other farm implements, with years of experience, strong R&D and engineering capabilities.
