Help CenterHOT Sale 3 Ton Wheel Loader With CE, With Fork, Hydraulic Heavy Construction Machine
Related Products
-
New Heavy Equipment Construction Machinery Wheel Loader 1.5ton 0.7CBMUS$ 1 - 2MOQ: 1 Set -
China 2ton Mini Wheel Loader ZL20F/JT920 Hot SaleUS$ 1 - 2MOQ: 1 Set
-
2.0 Ton CE Approved ZL20F Mini Wheel Loader Hot Sale, 2000kgNegotiableMOQ: 1 Set
-
0.8 TON Wheel Loader, Small Wheel Loader, ZL08F Small Wheel LoaderUS$ 1 - 2MOQ: 1 Set
-
Latest Export ZL20F 2.0 TON 1.0-1.3CBM Wheel LoaderNegotiableMOQ: 1 Set
Specifications
*CE/ISO9001:2008 wheel loader with Deutz/cummins engine
*WEICHAI Engine or Cummins engine
*Floating position valve
Specifications
Specification |
overall weight(kg) |
9500 |
L×W×H(mm) |
7050×2430X3120 |
|
rated bucket capacity(m3) |
1.7 |
|
Rated load(kg) |
3000 |
|
Maximum dump height (mm) |
3020/3250 |
|
Bucket indicator |
Yes |
|
Max. breakout force(KN) |
138 |
|
Engine |
Model |
WEICHAI Deutz TD226B/Cummins 6BT5.9-C125 |
Type |
In line,direct injection,four-stroke,liquid cooled |
|
|
Rated power(kw) |
92kw |
|
Rated speed(r/min) |
2200 |
|
Transmission system |
Model of torque converter |
YJ320B |
Type |
single-phase single-stage radial-inward turbine triplex |
|
Gearbox type |
Fixed-spindle power shift |
|
Gear shift |
2 gears ahead,2 gear astern |
|
Hydraulic system |
Distribution of work valve |
DF25 |
Working pump |
CBGj2100,CBGq2100 |
|
Steering system |
Type |
Articulated hydraulic steering |
Max. turning angle |
lift and right 36.5±1° |
|
Min turning radius(mm) |
5862 |
|
Brake system |
Brake type |
air-break brake |
Tyres |
Standard tyres |
17.5-25 |
|
Q1.How about your product quality?
A: Our products have passed the ISO,CE,EPA,SGS and BV certifications, so the quality is 100% guaranteed.
Q2. How about your company's service, especially after-sale service?
A: Kudat's Auto has been in this field for about 24 years,we can satisfy any of your demands in the first time .We always do our best to solve all the problems and put our customer's interests in the first place.
Q3 How about the warranty of your products?
A:Usually the warranty is one year or 1500H working time.
Q4:How about your payment?
A:T/T 30% in advance is better,then T/T 70% before shipment or L/C at sight.
Our advantages:
1 |
About 24 years Wholesaler experience in truck and truck parts field |
2 |
Specialization: Accurately meet your requirement, Experienced engineers serving for you |
3 |
Abundant products more than 100 famous manufacturers with owned factory. |
4 |
You“One-shop purchasing service” with spares under competitive price and best quality. |
5 |
Important partner with famous company and familiar with the market very well |
6 |
Good friendship with the famous carriers |
Our Main Products Covers
1)Wheel loader ZL06,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 ZL35and ZL50.
2)Site Dumper1- 2ton, self loading dumper1- 3ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type, 4 ton dumpers. 5 ton dumpers. 7ton dumpers. 10 ton dumpers.
3) Mini Tractors with different attachments from 20HP to 100HP.
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
