Help CenterLatest Export 1.0 Ton Wheel Loader, 0.5CBM Mini Wheel Loader ZL10F
Related Products
-
2 TON 1.0-1.2CBM China JT920 Wheel Loader With CE Well SaleUS$ 1 - 2MOQ: 1 Set -
China 800kg Wheel Loader, Small Wheel Loader With Snow BladeUS$ 1 - 2MOQ: 1 Set
-
China 2 Ton Mini Loader, JT920 Wheel Loader With Timber GrappleNegotiableMOQ: 1 Set
-
Mini Compact Wheel Loader 1000kg Wheel Loader For SaleUS$ 1 - 2MOQ: 1 Set
-
China Used Wheel Loader 936 Wheel Loader With Good ConditionUS$ 1 - 2MOQ: 1 Set
Model |
Mini Wheel Loader ZL10F |
Rated Loading Weight |
1000kg |
Rated Bucket Capacity |
0.5m3 |
Bucket type |
Heavy-duty bolt on teeth |
Max. Breakout Force |
32KN |
Operating Weight |
2880kg |
Engine |
|
Engine Model |
Changcai 4L68 |
Engine type |
In-line arrangement, water cooled, four cycle diesel engine |
Rated Power |
37KW |
Rated Speed |
2200 r/min(rpm) |
Operating Specifications |
|
Drive Type |
Four-wheel drive |
Min Turning Radius |
3890mm |
Driving System |
Static Hydraulic Driving |
Dumping Height |
2200mm |
Dumping Reach at max height |
850mm |
Min Base to the ground |
230mm |
Time of raise |
4sec. |
Hydraulic cycle time |
9sec. |
Overall Dimensions( L x W x H) |
4750x1720x2380mm |
Wheel distance |
1400mm |
Axle base |
1580mm |
Advantage & Application
1.Chinese C-ummin-s intercooled& turbocharged diesel engine;
2. Integral torque converter and gearbox(Germany ZF technology);
3. Driving axle with built-in free-wheel anti-slip differential;
4. Heavy-duty roller chains transmission balance box;
5.Popular swing-arm connecting rod operating mechanism;
6. Free-maintenance rolling-disc rotary device;
7. Double cylinders control the balde cutting angle;
8.Two sets of imported control valve (HUSCO Brand);
9. Imported hydraulic balancing valve for the blade lifting;
10. Steering system:center articulated mechanism and tilting front wheels to achieve crab-style movement;
11. Electro-hydraulic control: instrumentation monitoring & maintenance-free OPTIMA battery;
Our Services
1.Reply your inquiry in 24 working hours.
2.Company is the professional manufacturer, who carries an extensive range of new heavy duty equipments and agricultural machinery, such as wheel loaders, site dumpers, wheel excavators, tractors, and other farm implements, with years of experience, strong R&D and engineering capabilities.
